Запчасти Doosan Daewoo SEAT BODY PARTS

-

195-01095C

STAND ASS'Y

SC: D

-2шт.

1

901-00016

SEAT ASS'Y

SERIAL: 1001-1097

1шт.

1

901-00016A

SEAT ASS'Y

SERIAL: 1098

1шт.

2

195-01058B

BRACKET;SEAT MOUNTING

desc: SUPPORT

1шт.

2-1

195-01059B

BRACKET;SEAT

desc: . SUPPORT

1шт.

2-2

191-01292A

PALTE;SEAT

desc: . PLAQUE

1шт.

2-3

145-00019

STAY

desc: . ENTRETOISE

1шт.

2-4

2114-1058D29

WASHER

desc: . RONDELLE

1шт.

2-5

2705-9002

PIN;LOCK

desc: . GOUPILLE DE BLOCAGE

1шт.

2-6

2120-2166D5

BOLT M8X1.25X20

desc: . BOULON A 6 PANS

6шт.

2-7

2114-1898D2

WASHER;PLAIN M8

desc: . RONDELLE PLATE

6шт.

2-8

2114-2031D4

WASHER;SPRING M8

desc: . RONDELLE ELASTIQUE

6шт.

2-9

4130-1014B

SPRING

desc: . RESSORT

1шт.

2-10

S0504453

BOLT M6X1.0X12

desc: . BOULON A 6 PANS

2шт.

2-11

S5102303

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

2шт.

2-12

S5010313

WASHER;PLAIN M6

desc: . RONDELLE PLATE

2шт.

3

2120-2166D5

BOLT M8X1.25X20

desc: BOULON A 6 PANS

4шт.

4

2114-1898D2

WASHER;PLAIN M6

desc: RONDELLE PLATE

8шт.

40

2121-1311D2

NUT M8X1.25

desc: ECROU

4шт.

41

2114-2031D4

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.
