Запчасти Doosan Daewoo FUEL PIPING BODY PARTS

-

400-00333

FUEL PIPING ASS'Y

SC: D

-2шт.

1

30A60-00200

PUMP;FUEL

desc: POMPE

1шт.

2

195-00596A

BRACKET

desc: SUPPORT

1шт.

3

MM130552

SEDIMENTER;WATER

desc: SEDIMENTEUR

1шт.

4

2185-1247D144

HOSE D7.14-D13.49-1350L

desc: TUYAU FLEXIBLE

1шт.

5

2185-1247D145

HOSE D7.14-D13.49-1100L

desc: TUYAU FLEXIBLE

1шт.

6

2185-1247D98

HOSE D7.14-D13.49-500L

desc: TUYAU FLEXIBLE

1шт.

7

S0556753

BOLT M8X1.25X70

desc: BOULON A 6 PANS

2шт.

8

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

7шт.

9

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

3шт.

10

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

2шт.

11

S0505253

BOLT M8X1.0X30

desc: BOULON A 6 PANS

2шт.

12

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

13

2124-1509D5

CLIP

desc: ATTACHE

2шт.

14

S4012533

NUT M8X1.25

desc: ECROU

2шт.

15

S8450006

CLAMP;HOSE

desc: COLLIER

10шт.

16

2185-1247D99

HOSE D7.14-D13.49-600L

desc: TUYAU FLEXIBLE

1шт.

17

2114-1058D69

WASHER

desc: RONDELLE PLATE

2шт.

18

195-01348

BRACKET

desc: SUPPORT

1шт.

19

2185-1247D146

HOSE D7.49-D14.29-160L

SERIAL: 1001-1147

1шт.

19

2185-1247D149

HOSE D7.49-D14.29-250L

SERIAL: 1148

1шт.

20

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

21

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

1шт.

22

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

23

474-00030

FILTER;FUEL

desc: FILTRE

1шт.

24

MM400880

CLAMP;FILTER

desc: COLLIER

1шт.

25

2124-1353D9

CLIP

desc: ATTACHE

1шт.
