Запчасти Doosan Daewoo TRACK FRAME - 1300MM TRACK PARTS

-

604-00267A

TRACK ASS'Y

SC: D

-2шт.

1

604-00092C

FRAME;TRACK

SERIAL: 30001-30169

1шт.

1

604-00092E

FRAME;TRACK

SERIAL: 30170

1шт.

3

2621-3902B

COVER;MOTOR

desc: COUVERCLE

2шт.

4

2621-3903C

COVER;UNDER

desc: COUVERCLE

1шт.

5

270-00008A

ROLLER;TRACK

desc: ROULEAU

6шт.

6

2440-9266A

CYLINDER;GREASE

desc: VERIN

2шт.

7

270-00010A

IDLER;CRAWLER TRACK

desc: BARBOTIN

2шт.

8

401-00422

MOTOR;TRAVEL

desc: MOTEUR DE TRANSLATION

2шт.

9

2108-1044A

SPROCKET

desc: COURONNE DENTEE

2шт.

10

109-00130

BEARING;SWING

SERIAL: 30001-30560

1шт.

10

109-00130A

BEARING;SWING

SERIAL: 30561

1шт.

10A

180-00297D1

SEAL

desc: JOINT

1шт.

12

273-00038

SHOE;TRACK

desc: SHOE

2шт.

13

S0508853

BOLT M8X1.25X20

desc: BOULON

6шт.

14

S5102503

WASHER;SPRING M8

SERIAL: 30001-30169

10шт.

14

S5102503

WASHER;SPRING M8

SERIAL: 30170

18шт.

15

S5010513

WASHER;PLAIN M8

SERIAL: 30001-30169

10шт.

15

S5010513

WASHER;PLAIN M8

SERIAL: 30170

18шт.

16

S0508456

BOLT M8X1.25X12

desc: BOULON

4шт.

17

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON DE PLOT

34шт.

18

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

34шт.

20

S0515566

BOLT M12X1.75X45

desc: BOULON

18шт.

22

S0760766

BOLT M12X1.25X50

desc: BOULON

18шт.

23

K1002900

PLATE

SERIAL: 30170

2шт.

24

S0508953

BOLT

SERIAL: 30170

8шт.

25

K1014082

PIN;KNOCK

SERIAL: 30561

2шт.
