Запчасти Doosan Daewoo CONTROL VALVE MAIN PIPING(1)

-

420-00176C

CONTROL VALVE

desc: DISTRIBUTEUR

1шт.

1

1.451-00070

INLET BLOCK ASS'Y

desc: BLOC

1шт.

2

1.451-00171

BLOCK ASS'Y;TRAVEL(L)

desc: BLOC

1шт.

3

1.451-00010

BLOCK ASS'Y;ARM

desc: BLOC

1шт.

4

1.451-00020

BLOCK ASS'Y;OPT

desc: BLOC

1шт.

5

1.451-00171

BLOCK ASS'Y;TRAVEL(R)

desc: BLOC

1шт.

6

1.451-00016

BLOCK ASS'Y;BUCKET

desc: BLOC

1шт.

7

1.451-00012

BLOCK ASS'Y;BOOM

desc: BLOC

1шт.

8

1.451-00068

INLET BLOCK ASS'Y

desc: BLOC

1шт.

9

1.451-00014

BLOCK ASS'Y;BOOM SWING

desc: BLOC

1шт.

10

1.451-00018

BLOCK ASS'Y;DOZER

desc: BLOC

1шт.

11

1.451-00021

BLOCK ASS'Y;SWING

desc: BLOC

1шт.

12

1.451-00071

INLET BLOCK ASS'Y

desc: BLOC

1шт.

13

1.120-00038

BOLT;THROUGH

desc: BOULON

4шт.

14

S4010503

NUT

desc: ECROU

8шт.

15

1.420-00070

MAIN RELIEF VALVE

desc: CLAPET DE VANNE

2шт.

16

S8000221

O-RING

desc: JOINT TORIQUE

2шт.

17

1.420-00078

OVER LOAD RELIEF VALVE

desc: CLAPET DE VANNE

5шт.

18

S8000201

O-RING

desc: JOINT TORIQUE

6шт.

19

1.420-00025

ANTI CAVITATION VALVE

desc: CLAPET DE VANNE

1шт.

20

1.420-00071

MAIN RELIEF VALVE

desc: CLAPET DE VANNE

1шт.

21

S8010551

O-RING

desc: JOINT TORIQUE

11шт.

22

1.426-00025

POPPET;LOAD CHECK

desc: PLUNGEUR

6шт.

23

1.131-00140

SPRING;LOAD CHECK

desc: RESSORT

6шт.

24

1.181-00031

PLUG

desc: BOUCHON

9шт.

25

S8000141

O-RING

desc: JOINT TORIQUE

10шт.
