Запчасти Doosan Daewoo CONTROL STAND-R.H UPPER STRUCTURE

-

195-01095G

STAND ASS'Y

SC: D

-2шт.

3

2120-2166D5

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

4

2114-1898D2

WASHER;PLAIN M8

desc: RONDELLE PLATE

6шт.

5

195-01056A

BRACKET;STAND(RH)

desc: SUPPORT

1шт.

6

2125-1078B

CASE;UPPER

desc: CARTER

1шт.

7

621-01083A

COVER;SWITCH

desc: COUVERCLE

1шт.

8

195-01057A

BRACKET

desc: SUPPORT

1шт.

9

2120-2166D23

SCREW M5X0.8X20

desc: VIS

4шт.

10

2114-1898D4

WASHER;PLAIN M5

desc: RONDELLE PLATE

12шт.

11

195-01102A

BRACKET

desc: SUPPORT

1шт.

12

2120-2166D18

SCREW M5X0.8X10

desc: VIS

8шт.

13

195-01103A

BRACKET

desc: SUPPORT

1шт.

14

2120-2166D22

SCREW M3X0.5X12

desc: VIS

2шт.

41

2114-2031D4

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.
