Запчасти Doosan Daewoo OIL TANK UPPER STRUCTURE

-

470-00049

OIL TANK ASS'Y

SC: D

-2шт.

1

470-00048B

TANK;OIL

desc: RESERVOIR

1шт.

2

471-00042

FILTER;SUCTION

desc: FILTRE

1шт.

3

473-00023A

COVER

desc: COUVERCLE

1шт.

4

2180-1026D38

O-RING

desc: JOINT TORIQUE

1шт.

5

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

6

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

7

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

6шт.

8

528-00012

GAUGE;OIL

desc: INDICATEUR DE NIVEAU

1шт.

9

2181-1950D7

PLUG PF1/2

desc: BOUCHON

3шт.

10

S8000181

O-RING

desc: JOINT TORIQUE

3шт.

11

422-00028A

BREATHER;AIR

desc: RENIFLARD

1шт.

11A

180-00200

PACKING

desc: . JOINT

1шт.

12

S2202761

BOLT;SOCKET M5X0.8X8

desc: BOULON A 6 PANS CREUX

6шт.

13

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

3шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

15

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

16

2181-1950D2

PLUG PF3/8

desc: BOUCHON

1шт.

17

S8000141

O-RING

desc: JOINT TORIQUE

1шт.

18

161-00403

SPONGE

desc: EPONGE

1шт.
