Запчасти Doosan Daewoo STARTER ENGINE PARTS

1

30L66-10600

STARTER(12V-1.2KW)

desc: DEMARREUR

1шт.

1-1

47X11-02280

FRONT BRACKET ASS'Y

desc: . SUPPORT

1шт.

1-2

47X11-02329

CLUTCH SHAFT ASS'Y

desc: . ARBRE

1шт.

1-3

47X11-02228

GEAR SHAFT ASS'Y

desc: . PIGNON

1шт.

1-4

47X11-02290

INTERNAL GEAR ASS'Y

desc: . PIGNON

1шт.

1-5

47X11-02330

CLUTCH;OVER RUNNING

desc: . CLUTCH

1шт.

1-6

47X11-02207

GEAR ASS'Y

desc: . PIGNON

3шт.

1-7

47X11-02331

PISTON ASS'Y

desc: . PISTON

1шт.

1-8

47X11-02233

STOPPER;SET

desc: . ARRET

1шт.

1-9

47X11-02333

STOPPER;SET

desc: . ARRET

1шт.

1-10

47X11-02337

LEVER;SET

desc: . LEVIER

1шт.

1-11

47X11-02319

SWITCH ASS'Y

desc: . INTERRUPTEUR

1шт.

1-12

47X11-02237

SCREW SET

desc: . VIS

1шт.

1-13

47X11-02213

BALL

desc: . BILLE

1шт.

1-14

47X11-02320

PACKING

desc: . RONDELLE ETANCHE

1шт.

1-15

47X11-02285

ARMATURE

desc: . ARMATURE

1шт.

1-16

47X11-02326

YOKE ASS'Y

desc: . ETRIER

1шт.

1-17

47X11-02287

CONNECTOR BRUSH HOLD

desc: . BIELLE

1шт.

1-18

47X11-02327

REAR BRACKET ASS'Y

desc: . SUPPORT

1шт.

1-19

47X11-02289

BOLT

desc: . BOULON A 6 PANS

2шт.
