Запчасти Doosan Daewoo MAIN MOVING PARTS ENGINE PARTS

1

30L17-00010

PISTON STD

desc: PISTON

3шт.

2

30L17-00020

PISTON 0.25

desc: PISTON

3шт.

3

30L17-00030

PISTON 0.50

desc: PISTON

3шт.

4

MM433713

RING SET;PISTON STD

desc: BAGUE

3шт.

5

MM434344

RING SET;PISTON 0.25

desc: BAGUE

3шт.

6

MM434345

RING SET;PISTON 0.50

desc: BAGUE

3шт.

7

30L19-00051

CONNECTING ROD ASS'Y

desc: TIGE

3шт.

7-1

MD000704

NUT

desc: . ECROU

6шт.

7-2

MD000-705

BOLT;CONNECTING

desc: . BOULON A 6 PANS

6шт.

7-3

ROD;CONNECTING

SC: D

3шт.

7-4

CAP;CONNECTING

SC: D

3шт.

8

MM438-80601

METAL SET;CON-ROD STD

desc: METAL

3шт.

9

MM438-80701

METAL SET;CON-ROD 0.25

desc: METAL

3шт.

10

MM438-80801

METAL SET;CON-ROD 0.50

desc: METAL

3шт.

11

30L20-00500

CRANK;SHAFT

desc: VILEBREQUIN

1шт.

12

30L20-00700

PULLEY;CRANK SHAFT

desc: POULIE

1шт.

13

MM432887

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

14

MF430845

NUT;JAM

desc: ECROU

1шт.

15

MF450009

WASHER;PLAIN

desc: RONDELLE

1шт.

16

MF450409

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

17

MF476214

KEY;WOODRUFF

desc: KEY

2шт.

18

MM437-477

FLYWHEEL ASS'Y

desc: VOLANT

1шт.

18-1

MD030629

GEAR;RING

desc: . PIGNON

1шт.

18-2

FLYWHEEL

SC: D

1шт.

19

MD075878

BOLT;FLYWHEEL

desc: BOULON A 6 PANS

4шт.
