Запчасти Doosan Daewoo CRANK CASE ENGINE PARTS

1

MM432677

COVER

desc: COUVERCLE

1шт.

2

30L07-05100

GASKET

desc: JOINT

1шт.

3

MM432-65004

CYLINDER BLOCK SUB ASS'Y

desc: BLOC CYLINDRE

1шт.

3-1

MD000427

CAP;SEALING

desc: . BOUCHON

3шт.

3-2

MD016230

BOLT;BEARING CAP

desc: . BOULON A 6 PANS

8шт.

3-3

MF665538

CAP;SEALING

desc: . BOUCHON

2шт.

3-4

CAP ASS'Y

SC: D

1шт.

4

30L07-01800

PLUG;TAPER

desc: BOUCHON

3шт.

5

MM409645

PIN;DOWEL

desc: BROCHE

2шт.

6

MM433115

SHAFT;IDLER

desc: ARBRE

1шт.

7

MM430613

GUIDE;OIL LEVEL

desc: GUIDE

1шт.

8

MF472404

PIN;DOWEL

desc: BROCHE

1шт.

9

MF665510

PLUG;EXPANSION

desc: BOUCHON

1шт.

10

MS471101

BUSHING;KNOCK

desc: GARNISSAGE CAOUTCHOUC

2шт.

11

MS471102

BUSHING;KNOCK

desc: GARNISSAGE CAOUTCHOUC

1шт.

12

MS471105

BUSHING;KNOCK

desc: GARNISSAGE CAOUTCHOUC

2шт.

13

MS471107

BUSHING

desc: GARNISSAGE CAOUTCHOUC

3шт.

14

MS661141

PLUG;TAPER

desc: BOUCHON

1шт.

15

MM432214

SEAL;SIDE

desc: JOINT

4шт.

16

MM433363

PLATE;FRONT W/O PTO

desc: PLAQUE

1шт.

17

MM432065

CASE;OIL SEAL

desc: CARTER

1шт.

18

30L07-05300

GASKET;FRONT PLATE

desc: JOINT

1шт.

19

30L07-05200

GASKET;OIL SEAL CASE

desc: JOINT

1шт.

20

MD016317

SEAL;OIL REAR

desc: JOINT D'HUILE

1шт.

21

30L07-00700

SHAFT;OIL FILTER

desc: ARBRE

1шт.

22

MD000269

PLUG;TAPER

desc: BOUCHON

1шт.

23

MF101228

BOLT

desc: BOULON A 6 PANS

6шт.

24

MF240051

BOLT;WITH WASHER

desc: BOULON A 6 PANS

2шт.

25

MF241224

BOLT;WITH WASHER

desc: BOULON A 6 PANS

7шт.

26

MM438799

METAL SET;CRANK SHAFT

desc: METAL;CRANK

1шт.

27

MM438800

METAL SET;CRANK SHAFT 0.25

SC: US

1шт.

28

MM438801

METAL SET;CRANK SHAFT 0.50

SC: US

1шт.

29

MM438-720

HOUSING;FLYWHEEL

desc: CARTER

1шт.

30

MF241282

BOLT;WITH WASHER

desc: BOULON A 6 PANS

6шт.

31

05534-16000

PLUG

desc: BOUCHON

1шт.

32

MF100083

BOLT

desc: BOULON A 6 PANS

4шт.

33

MM431-251

GAUGE;OIL LEVEL

desc: JAUGE DE HUILE

1шт.
