Запчасти Doosan Daewoo MAIN PIPING(1) BODY PARTS

-

2400-1862

MAIN PIPING

SC: D

-2шт.

1

2420-9528

VALVE;CONTROL

SERIAL: 1001-1287

1шт.

1

2420-9528B

VALVE;CONTROL

SERIAL: 1288

1шт.

2

2159-1198

BRACKET;VALVE

SERIAL: 1001-1287

2шт.

3

S0508853

BOLT M8X1.25X20

SERIAL: 1001-1287

8шт.

4

S5102503

WASHER;SPRING

SERIAL: 1001-1287

8шт.

4

S5102503

WASHER;SPRING

SERIAL: 1288

7шт.

5

2401-9253

MOTOR;SWING

desc: MOTEUR D'ORIENTATION

1шт.

6

S0515453

BOLT M12X1.75X40

desc: BOULON A 6 PANS

4шт.

7

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

4шт.

8

S8000141

O-RING P14

desc: JOINT TORIQUE

3шт.

9

S8000181

O-RING P18

desc: JOINT TORIQUE

6шт.

10

2181-2714

ELBOW PFO1/2X3/8

SERIAL: 1001-1287

3шт.

10

2181-2714

ELBOW PFO1/2X3/8

SERIAL: 1288

2шт.

11

2181-1126D6

ADAPTER PFO1/2X1/2

desc: RACCORD ADAPTATEUR

1шт.

12

2181-1702D44

ELBOW PFO1/2X3/8

desc: COUDE

1шт.

13

2181-1702D5

ELBOW PFO3/8X3/8

desc: COUDE EN S

2шт.

14

2181-1702D5

ELBOW PFO3/8X3/8

desc: COUDE EN S

1шт.

15

2181-2047

PLUG M10X1.0

SERIAL: 1001-1287

3шт.

15

2181-2047

PLUG M10X1.0

SERIAL: 1288

2шт.

16

2181-1126D83

ADAPTER PFO1/2X1/2

desc: RACCORD ADAPTATEUR

1шт.

17

2184-1060D114

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.

18

2184-1060D171

HOSE PF3/8-1000L

desc: TUYAU FLEXIBLE

1шт.

19

2184-1060D28

HOSE PF3/8-850L

desc: TUYAU FLEXIBLE

1шт.

20

2184-1036D159

HOSE PF1/2-900L

desc: TUYAU FLEXIBLE

1шт.

21

2184-1036D121

HOSE PF1/2-520L

desc: TUYAU FLEXIBLE

1шт.

22

2184-1026D238

HOSE PF3/8-1000L

SERIAL: 1001-1307

1шт.

23

2184-1026D66

HOSE PF3/8-600L

desc: TUYAU FLEXIBLE

1шт.

24

2161-1908D2

PLATE;RUBBER

SERIAL: 1041

1шт.

25

2124-1084D3

CLIP;BAND

SERIAL: 1041

3шт.

26

195-00304A

BRACKET

SERIAL: 1288

1шт.

27

S0508953

BOLT M8X1.25X22

SERIAL: 1288

7шт.

28

2181-1702D43

ELBOW PFO1/2X3/8

SERIAL: 1288

1шт.
