Запчасти Doosan Daewoo WORK BODY ASSY-DOZER HYDRAULIC PARTS

1

2371217042701

BODY-WORK

SC: D

1шт.

2

2371420140505

SPOOL

SC: D

1шт.

3

0401101010000

O-RING 1B P10A

desc: JOINT TORIQUE

2шт.

4

0440211010000

RING;BACK-UP

desc: BAGUE DE SOUTIEN

2шт.

5

0401100010010

O-RING 1B P10

desc: JOINT TORIQUE

2шт.

6

2371416994701

SEAT;O-RING

desc: SIEGE DE JOINT TORIQUE

2шт.

7

2371416994801

SEAT;SPRING

desc: SIEGE DE RESSORT

2шт.

8

0031110501064

SCREW

desc: VIS

2шт.

9

0002010504551

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

2шт.

10

2371416994601

CAP;SPRING RETURN

desc: CHAPEAU

1шт.

11

6257417185601

SPRING;SPOOL

desc: RESSORT

1шт.

12

6251420018001

SCREW

desc: VIS

1шт.

13

2371420018201

SPACER

desc: BAGUE

1шт.

14

2332090701014

POPPET;CHECK VALVE

desc: SOUPAPE SOULEVANTE

1шт.

15

6257417053001

SPRING;CHECK VALVE

desc: RESSORT

1шт.

16

2371416994501

PLUG;CHECK VALVE

desc: BOUCHON

1шт.

17

0401100011010

O-RING 1B P11

desc: JOINT TORIQUE

1шт.

18

0403100012710

O-RING ARP 1B127

desc: JOINT TORIQUE

1шт.

19

0401100014010

O-RING 1B P14

desc: JOINT TORIQUE

2шт.

20

6251416995201

PLUG PF3/8

desc: BOUCHON

2шт.
