Запчасти Doosan Daewoo LOW PIPING BODY PARTS

-

2400-1563

LOW PIPING ASS'Y

SC: D

-2шт.

1

2185-1002D150

HOSE 370L

desc: TUYAU FLEXIBLE

2шт.

2

S8000181

O-RING P18

desc: JOINT TORIQUE

4шт.

3

181-00725

ELBOW PFO1/2

desc: COUDE

2шт.

4

S8450018

CLAMP;HOSE

desc: COLLIER

10шт.

6

S8000141

O-RING P14

desc: JOINT TORIQUE

8шт.

7

2181-2295D12

ELBOW PFO3/8-PF3/8

desc: COUDE

2шт.

8

2181-2419D2

ELBOW PFO3/8-PF3/8

desc: COUDE

2шт.

9

DS2281095

ADAPTER PFO3/8-PF3/8

desc: COUDE

1шт.

10

2184-1026D336

HOSE PF3/8-530L

desc: TUYAU FLEXIBLE

1шт.

11

2181-1702D5

ELBOW PFO3/8-PF3/8

desc: COUDE EN S

1шт.

12

2184-1026D329

HOSE PF3/8-740L

desc: TUYAU FLEXIBLE

1шт.

13

2181-2436

ADAPTER PFO3/8

desc: RACCORD ADAPTATEUR

1шт.

14

2185-1002D71

HOSE 55L

desc: TUYAU FLEXIBLE

1шт.

15

2181-2435

ELBOW PFO3/8-PF3/8

desc: COUDE

1шт.

16

2181-2428A

ADAPTER PFO3/8

desc: RACCORD ADAPTATEUR

1шт.

17

2185-1002D72

HOSE 500L

desc: TUYAU FLEXIBLE

1шт.

18

S8000111

O-RING

desc: JOINT TORIQUE

1шт.

19

2181-1702D3

ELBOW PFO1/4-PF3/8

desc: COUDE

1шт.

20

2184-1052D43

HOSE PF3/8-380L

desc: TUYAU FLEXIBLE

1шт.

21

2181-2427

ADAPTER PFO1/2-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

22

2181-1950D3

PLUG PFO1/2

desc: BOUCHON

2шт.

23

2181-2426

ADAPTER PFO1/2

desc: RACCORD ADAPTATEUR

1шт.

24

S2208663

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

25

S8450016

CLAMP

desc: COLLIER

2шт.

26

2185-1002D73

HOSE 450L

desc: TUYAU FLEXIBLE

1шт.

27

2193-1283B

PIPE

desc: CONDUITE

1шт.

28

2114-1058D63

WASHER

desc: RONDELLE

1шт.

29

2185-1002D74

HOSE 400L

desc: TUYAU FLEXIBLE

1шт.

30

2185-1374

HOSE;VINYL

desc: TUYAU FLEXIBLE PVC

1шт.

31

2185-1375A

HOSE;VINYL

desc: TUYAU FLEXIBLE PVC

1шт.
