Запчасти Doosan Daewoo FRONT PLANETARY GEAR ASSY HYDRAULIC PARTS

1

3198723

COVER

desc: COUVERCLE

2шт.

2

70572

GASKET 3.53X278.83

desc: JOINT

2шт.

3

3112993

SAMPLE;PLATE

desc: PLAQUE

2шт.

4

70311

SCREW M10X25

desc: VIS

8шт.

5

3199973

SUPPORT

desc: SUPPORT

2шт.

6

3138703

PIN

desc: BROCHE

6шт.

7

70507

PLUG M22X1.5

desc: BOUCHON

2шт.

8

70111

GASKET D22X28X1.5

desc: JOINT

2шт.

9

3130043

THRUST PLATE SHIM 1.5mm

desc: BUTEE

6шт.

10

3127393

BEARING

desc: PALIER

6шт.

11

3121773

SPACER

desc: BAGUE D'ECARTEMENT

6шт.

12

3121673

GEAR;DIFFERENTIAL PINION

desc: ENGRENAGE

6шт.

13

3127363

THRUST PLATE SHIM 3mm

desc: BUTEE

6шт.

14

3121683

GEAR;DIFFERENTIAL SIDE

desc: ENGRENAGE

2шт.

15

70201

RING;SNAP D55

desc: BAGUE

2шт.

16

3138633

DISK;DRUM BRAKE

desc: DISQUE

2шт.

17

3146743

DISK;BRAKE

desc: DISQUE

8шт.

18

3146623

PRESSURE PLATE SHIM 4.0mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3200513

PRESSURE PLATE SHIM 4.25mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3146833

PRESSURE PLATE SHIM 4.5mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3146843

PRESSURE PLATE SHIM 5.0mm

desc: CARTOUCHE DE PRESSION

8шт.

19

3138243

PIN

desc: BROCHE

12шт.

20

3120843

RING;SNAP

desc: CIRCLIP

2шт.

21

3138663

PRESSURE;PLATE

desc: CARTOUCHE DE PRESSION

2шт.

22

3143523

SPRING

desc: RESSORT

2шт.

23

3138233

RING

desc: BAGUE

2шт.

24

3128073

SMALL;PLATE

desc: PLAQUE

4шт.

25

3138603

NUT;ADJUSTING

desc: ECROU

2шт.

26

70576

RING;SNAP D92

desc: BAGUE

2шт.

27

3138623

THRUST;PLATE

desc: BUTEE

2шт.

28

70566

BEARING D170X230X33

desc: PALIER

2шт.

29

3138593

SUPPORT;WHEEL

desc: SUPPORT

2шт.

30

3138583

WHEEL

desc: VOLANT

2шт.

31

3220823

HUB;WHEEL

desc: MOYEU DE FIXATION

2шт.

32

3120303

BOLT;STUD

desc: BOURON A 6 PANS

32шт.

33

70574

GASKET 5.34X109.5

desc: JOINT

2шт.

34

3149523

PISTON

desc: PISTON

2шт.

35

70426

GASKET 5.33X133.7

desc: JOINT

2шт.

36

70573

BEARING D140X195X29

desc: PALIER

2шт.

37

71198

GASKET 178X205X20

desc: JOINT

2шт.

37

71306

GASKET 178X205X17.5

desc: JOINT

2шт.

37

71528

GASKET 178X205X17.5

desc: JOINT

2шт.

37

71531

GASKET 200X170X17.5

desc: JOINT

2шт.

38

3199853

WHEEL HUB SPINDLE COMPLETE(R.H.)

desc: VOLANT

1шт.

39

70673

BREATHER;OIL

desc: ENSEMBLE RENIFLARD

2шт.

40

70382

SCREW M8X25

desc: VIS

12шт.

41

70565

GASKET 3.53X430.66

desc: JOINT

22шт.

42

3199873

WHEEL HUB SPINDLE COMPLETE(L.H.)

desc: VOLANT

1шт.

43

3138103

SCREW M22X1.5X70

desc: VIS

32шт.

44

3119623

NUT

desc: ECROU

32шт.

44

3119633

NUT

SC: R

32шт.

45

3199623

RING

desc: BAGUE

2шт.

110

3199983

COMPLETE SUPPORT

desc: SUPPORT

2шт.
