Запчасти Doosan Daewoo CONTROL VALVE HYDRAULIC PARTS

|$1

4420-9269

CONTROL VALVE 2 SPOOL

desc: BLOC DE COMMANDE

1шт.

|$2

4420-9442

CONTROL V/V(3)

desc: BLOC DE COMMANDE

1шт.

1

08700065

PLATE;COVER(L.H.)

desc: PLAQUE

1шт.

2

08694123

SECT.;V90-4WAY

desc: PLONGEUR

1шт.

3

08697022

SECT.;V90-4WAY

desc: PLONGEUR

1шт.

4

08694124

SECT.;V90-4WAY

desc: PLONGEUR

1шт.

5

08736021

PLATE;COVER(R.H.)

desc: PLAQUE

1шт.

6

10911003

STUD(3-SPOOL)

desc: GOUJON M12x1.25x1.75x65

4шт.

7

22063003

SEAL(3-SPOOL)

desc: JOINT

1шт.

7A

21933001

SEAL

desc: JOINT

4шт.

7B

21934001

SEAL

desc: JOINT

8шт.

7C

21987001

SEAL

desc: JOINT

4шт.

8

09310108

NUT

desc: ECROU

4шт.

9

10911002

STUD(2-SPOOL)

desc: GOUJON M12x1.25x1.75x65

4шт.

10

22063002

SEAL(2-SPOOL)

desc: JOINT

1шт.

10A

21933001

SEAL

desc: JOINT

3шт.

10B

21934001

SEAL

desc: JOINT

6шт.

10C

21987001

SEAL

desc: JOINT

3шт.
