Запчасти Doosan Daewoo REAR PLANETARY GEAR ASSY HYDRAULIC PARTS

1

3198723

COVER

desc: COUVERCLE

2шт.

2

70572

GASKET D3.53X279.99

desc: JOINT

2шт.

3

3112993

SAMPLE PLATE

desc: PLAQUE

2шт.

4

70311

SCREW M10X25

desc: VIS

8шт.

5

3200293

SUPPORT

desc: SUPPORT

2шт.

6

3140213

PIN

desc: BROCHE

6шт.

7

70507

PLUG M22X1.5

desc: BOUCHON

2шт.

8

70111

GASKET D22X28X1.5

desc: JOINT

2шт.

9

3130043

THRUST PLATE SHIM 1.5mm

desc: BUTEE

6шт.

10

3127383

BEARING

desc: PALIER

6шт.

11

3120933

SPACER

desc: BAGUE D'ECARTEMENT

6шт.

12

3163713

GEAR;DIFFERENTIAL PINION

desc: ENGRENAGE

6шт.

13

3127353

THRUST PLATE SHIM 3.00mm

desc: BUTEE

6шт.

14

3163663

GEAR;DIFFERENTIAL SIDE

desc: ENGRENAGE

2шт.

15

70395

RING;SNAP D50

desc: BAGUE

2шт.

16

3150693

DISK;DRUM BRAKE

desc: DISQUE

2шт.

17

3146743

DISK;BRAKE

ICA: Y

8шт.

18

3146823

PRESSURE PLATE SHIM 4mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3200513

PRESSURE PLATE SHIM 4.25mm

ICA: Y

8шт.

18

3146833

PRESSURE PLATE SHIM 4.5mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3146843

PRESSURE PLATE SHIM 5mm

desc: CARTOUCHE DE PRESSION

8шт.

19

3140153

PIN

desc: BROCHE

12шт.

20

3120843

RING;SNAP

desc: CIRCLIP

2шт.

21

3140163

PRESSURE PLATE

desc: CARTOUCHE DE PRESSION

2шт.

22

3137863

SPRING

desc: RESSORT

2шт.

23

3137873

RING

desc: BAGUE

2шт.

24

3128073

SAMPLE PLATE

desc: PLAQUE

4шт.

25

3130133

NUT;ADJUSTING

desc: ECROU

2шт.

26

70502

RING;SNAP Ґх75mm

desc: BAGUE

2шт.

27

3137813

PLATE;THRUST

desc: PLAQUE DE BUTEE

2шт.

28

70564

BEARING Ґх130XҐх200XҐх45

desc: PALIER

2шт.

29

3170763

SUPPORT;WHEEL

desc: SUPPORT

2шт.

30

3140103

WHEEL

desc: VOLANT

2шт.

31

3200333

HUB;WHEEL

desc: MOYEU DE FIXATION

2шт.

32

3120303

BOLT;STUD

desc: GOUJON

32шт.

33

70720

GASKET Ґх5.34X104.14

desc: JOINT

2шт.

34

3149513

PISTON

desc: PISTON

2шт.

35

70430

GASKET 5.33X130.2

desc: JOINT

2шт.

36

70573

BEARING D140X195X29

desc: PALIER

2шт.

37

71531

GASKET D200X170X17.5

desc: JOINT

2шт.

37

71198

GASKET D150X190X19

desc: JOINT

2шт.

37

71306

GASKET

SC: R

-2шт.

37

71528

GASKET

SC: R

-2шт.

38

3200343

WHEEL HUB SPINDLE COMPLETE(R.H.)

desc: VOLANT

1шт.

39

70673

BREATHER;OIL

desc: ENSEMBLE RENIFLARD

2шт.

40

70382

SCREW M8X25

desc: VIS

12шт.

41

70579

GASKET D3.53X405.26

desc: JOINT

2шт.

42

3200363

WHEEL HUB SPINDLE COMPLETE(L.H.)

desc: VOLANT

1шт.

43

70625

SCREW M20X1.5X55

desc: VIS

32шт.

44

3119623

NUT

desc: ECROU

32шт.

44

3119633

NUT

SC: R

-2шт.

110

3200283

SUPPORT COMPLETE

desc: SUPPORT

2шт.
