Запчасти Doosan Daewoo EMERGENCY STEER KIT FRONT PARTS

-

4400-1660

EMERGENCY STEER KIT

SC: D

-2шт.

1

4401-9187

PUMP KIT;EMER. STEER

desc: POMPE

1шт.

2

4420-9356

VALVE;SWITCH

desc: VANNE

1шт.

3

2181-1950D1

PLUG PFO1/4"

desc: BOUCHON

1шт.

4

2184-1036D296

HOSE PF3/4-1000L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1089D30

HOSE PF1"+5000PSI

desc: TUYAU FLEXIBLE

1шт.

6

2184-1089D31

HOSE PF1"+5000PSI

desc: TUYAU FLEXIBLE

1шт.

7

2184-1026D333

HOSE PF1/4-260L

desc: TUYAU FLEXIBLE

1шт.

8

2184-1036D263

HOSE PF3/4-2300L

desc: TUYAU FLEXIBLE

1шт.

9

S5110601

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

10

4191-3645

PLATE

desc: PLAQUE

1шт.

11

S0515253

BOLT

desc: BOULON A 6 PANS

2шт.

12

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

13

S2212061

BOLT;SOCKET

desc: BOULON 6 PANS CREUX

2шт.

14

2181-1126D22

ADAPTER PFO1-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

15

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

16

2181-1917D44

ADAPTER M22X1.5-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

17

S8180341

PACKING

desc: RONDELLE D'ETANCHEITE

1шт.

18

2181-1917D45

ADAPTER M42X2-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

19

S8180631

SEAL RING

desc: BAGUE D'ETANCHEITE

3шт.

20

2181-1917D43

ADAPTER M42X2-PF1

desc: RACCORD ADAPTATEUR

1шт.

21

4181-2532

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

22

4181-2550

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

23

S8180521

SEAL RING

desc: BAGUE D'ETANCHEITE

1шт.

24

2181-2100D6

TEE PT1/2-PF1/2-PF3/4

desc: TE

1шт.

25

S8000111

O-RING

desc: JOINT TORIQUE

1шт.

26

2181-1917D46

ADAPTER M48X2-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

27

S8180691

SEAL RING

desc: BAGUE D'ETANCHEITE

1шт.

35

4140-1057

PIPE

desc: CONDUITE

1шт.

36

2181-9078

FLANGE

desc: BRIDE

2шт.

37

2114-1058D10

WASHER;PLAIN

desc: RONDELLE

2шт.

38

2114-1058D30

WASHER;PLAIN

desc: RONDELLE

2шт.

39

2180-1026D19

O-RING

desc: JOINT TORIQUE

2шт.

40

S2212261

BOLT;SOCKET

desc: BOULON 6 PANS CREUX

4шт.
