Запчасти Doosan Daewoo OIL PUMP ENGINE PARTS

1

65.05204-0036

GEAR;IDLE

desc: PIGNON FOU

1шт.

2

06.31420-0311

BEARING;BALL #6006

desc: ROULEMENT A BILLES #6006

2шт.

2

06.31420-0314

BEARING;BALL #6006

desc: ROULEMENT A BILLES #6006

2шт.

3

06.29020-0132

RING;SNAP

desc: CIRCLIP

2шт.

4

65.05205-0018

PIN;IDLE GEAR

desc: GOUPILLE DE PIGNON FOU

1шт.

5

06.22220-0905

PIN;SPIRAL LOCK 4X10

desc: BROCHE

1шт.

5

06.22220-0905

PIN;SPIRAL LOCK 4X10

desc: BROCHE

6

06.29010-0125

RING;SNAP 30X2

desc: CIRCLIP

1шт.

7

65.90030-0002

BOLT;SOCKET HEAD

desc: BOULON 6 PANS CREUX

1шт.

7

65.90030-0009

BOLT;SOCKET HEAD

desc: BOULON 6 PANS CREUX

1шт.

8

65.05100-6023

OIL PUMP ASS'Y

desc: POMPE A HUILE

1шт.

9

65.05201-0034

GEAR;OIL PUMP DRIVE

desc: ENSEMBLE POMPE A HUILE

1шт.

10

65.05102-0015

HOUSING;OIL PUMP

desc: BOITIER DE POMPE A HUILE

1шт.

11

65.05104-0080

GEAR;PUMP

desc: PIGNON DE POMPE

1шт.

11

65.05104-5004

GEAR;PUMP

desc: PIGNON DE POMPE

1шт.

12

65.05104-0081

GEAR;PUMP

desc: PIGNON DE POMPE

1шт.

12

65.05104-5003

GEAR;PUMP

desc: PIGNON DE POMPE

1шт.

13

65.05103-5012

OIL PUMP COVER ASS'Y

desc: ENSEMBLE COUVERCLE POMPE A HUILE

1шт.

13

65.93020-0007

BUSH

desc: COUSSINET

1шт.

14

65.05103-5015

OIL PUMP COVER ASS'Y

desc: ENSEMBLE COUVERCLE POMPE A HUILE

1шт.

14

65.93020-0007

BUSH

desc: COUSSINET

1шт.

14

65.93020-0006

BUSH

desc: COUSSINET

1шт.

15

06.22022-0909

PIN;DOWEL 6M6X14

desc: BROCHE

4шт.

16

06.01013-9118

BOLT;HEX. M8X65

desc: BOULON A 6 PANS

4шт.

17

65.90510-0012

NUT;LOCK

desc: ECROU DE BLOCAGE

4шт.

18

06.29141-0207

KEY;WOODRUFF

desc: CLAVETTE WOODRUFF

1шт.

19

06.16050-0311

WASHER;LOCK

desc: RONDELLE FREIN

1шт.

20

06.11053-9217

NUT;HEX

desc: ECROU 6 PANS

1шт.

21

06.22022-0907

PIN;DOWEL 6M6X10

desc: BROCHE

2шт.

22

65.90801-0038

WASHER;LOCK

desc: RONDELLE FREIN

2шт.

23

06.01013-9215

BOLT;HEX. M10X50

desc: BOULON A 6 PANS

2шт.

23

06.01913-3221

BOLT;HEX. M10X50

desc: BOULON A 6 PANS

2шт.

24

65.05410-0025

PLUNGER;VALVE

desc: PLONGEURR DE SOUPAPE

1шт.

25

65.97601-0110

SPRING;COMPRESSION

desc: RESSORT DE COMPRESSION

1шт.

26

65.90310-0104

SCREW;PLUG

desc: BOUCHON FILETE

1шт.
