Запчасти Doosan Daewoo ROPS/FOPS ASSY BODY PARTS

-

4621-4221

ROPS/FOPS ASS'Y

SC: D

-2шт.

1

4621-4182A

COVER

desc: COUVERCLE

1шт.

1

4621-4182C

COVER

SERIAL: 16

1шт.

1

4621-4182E

COVER

desc: COUVERCLE

1шт.

1

4621-4182G

COVER

SERIAL: 96-108

1шт.

1

4621-4182H

COVER

SERIAL: 109

1шт.

1

4621-4182I

COVER

desc: COUVERCLE

1шт.

2

4195-4493A

BRACKET(RH)

desc: SUPPORT

1шт.

3

4195-4494A

BRACKET(L.H)

desc: SUPPORT

1шт.

4

S0733661

BOLT M24X2X50

desc: BOULON A 6 PANS

16шт.

5

S5103301

WASHER;SPRING M24

desc: RONDELLE ELASTIQUE M24

32шт.

6

S0774761

BOLT M24X2X70

desc: BOULON A 6 PANS

16шт.

7

S4037333

NUT M24X2

desc: ECROU

16шт.
