Запчасти Doosan Daewoo REAR FENDER(OPTION) BODY PARTS

-

4621-4268

REAR FENDER ASS'Y(OPTION)

SC: D

-2шт.

1

4621-4277

FENDER;REAR(RH)

desc: AILE ARRIERE

1шт.

2

4621-4278

FENDER;REAR(LH)

desc: AILE ARRIERE

1шт.

3

S0511953

BOLT M10X1.5X22

desc: BOULON A 6 PANS

20шт.

4

4195-4469A

BRACKET;REAR

desc: SUPPORT

2шт.

5

4195-4468A

BRACKET;FRONT

desc: SUPPORT COMBINE AVANT GAUCHE

2шт.

6

S0508753

BOLT M8X1.25X18

desc: BOULON A 6 PANS

12шт.

7

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

12шт.

8

4123-4102

PIN

desc: BROCHE

4шт.

9

S6710025

NIPPLE;GREASE

desc: GRAISSEUR

8шт.

10

4195-4467

BRACKET;PILOT

desc: SUPPORT

2шт.

11

4114-4065

SHIM

desc: CALE

4шт.

12

4195-4465

BRACKET(LH)

desc: SUPPORT

1шт.

13

4195-4466

BRACKET(RH)

desc: SUPPORT

1шт.

14

S0552153

BOLT M5X0.8X25

desc: BOULON A 6 PANS

4шт.

15

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

4шт.

16

S4012233

NUT M5X0.8

desc: ECROU

4шт.

18

4143-9002

KIT;FENDER LATCH

desc: KIT DE REPARATION

1шт.

19

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

28шт.

20

4195-4558

BRACKET

desc: SUPPORT

2шт.

21

S0558053

BOLT M10X1.5X28

desc: BOULON A 6 PANS

8шт.

22

4161-4056

PLATE;RUBBER

desc: PLAQUE CAOUTCHOUC

2шт.

23

4191-4405

PLATE

desc: PLAQUE

2шт.

24

S0509253

BOLT M8X1.25X30

desc: BOULON A 6 PANS

6шт.

25

S4012533

NUT M8X1.25

desc: ECROU

6шт.

26

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

6шт.
