Запчасти Doosan Daewoo LIS PIPING(OPTION) BODY PARTS

-

4400-4111

LIS PIPING ASS'Y

SC: D

-2шт.

1

2180-1026D19

O-RING 1"SAE

desc: JOINT TORIQUE

2шт.

2

2181-9078

FLANGE;SPLIT 1"SAE

desc: FLASQUE

4шт.

3

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

24шт.

4

4420-9446A

VALVE;SOLENOID

desc: VANNE SOLENOIDE

2шт.

5

4183-4651

PIPE;RETURN

desc: CONDUITE DE RETOUR

1шт.

6

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

4шт.

7

S4012533

NUT M8X1.25

desc: ECROU

4шт.

8

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON 6 PANS CREUX

16шт.

9

S0758253

BOLT M10X1.25X35

desc: BOULON A 6 PANS

8шт.

10

S8010300

O-RING

desc: JOINT TORIQUE

2шт.

11

4183-4652

PIPE

desc: CONDUITE

1шт.

12

4183-4653

PIPE

desc: CONDUITE

1шт.

13

4460-9404

KIT;ACCUMULATOR

desc: KIT DE REPARATION

2шт.

13A

0531013700

ACCUMULATOR

desc: . RESERVOIR

1шт.

13B

1533345031

ADAPTER;PIECE

desc: . RACCORD ADAPTATEUR

1шт.

13C

1530210076

RING;SEALING

desc: . BAGUE

1шт.

13D

1531316003

CLAMP;STRAP

desc: . COLLIER

1шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

8шт.

15

2181-9079

FLANGE;SPLIT 3/4"SAE3000

desc: FLASQUE

4шт.

16

2180-1026D2

O-RING 3/4"SAE

desc: JOINT TORIQUE

2шт.

17

S2214261

BOLT;SOCKET M10X1.5X130

desc: BOULON 6 PANS CREUX

8шт.

19

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

4шт.

20

S0556053

BOLT M8X1.25X35

desc: BOULON A 6 PANS

4шт.

21

4183-4650

PIPE;ACCUMULATOR(RH)

desc: CONDUITE

1шт.

22

4183-4649

PIPE;ACCUMULATOR(LH)

desc: CONDUITE

1шт.

23

S8000241

O-RING PF3/4"

desc: JOINT TORIQUE

2шт.

24

4181-4213

BLOCK;MANIFOLD

desc: BLOC

1шт.

25

2184-1094D12

HOSE 3/4"STD-1"STDXL640

desc: TUYAU FLEXIBLE

1шт.

26

2184-1082D65

HOSE 3/4"STD-1"STDXL420

desc: TUYAU FLEXIBLE

1шт.
