Запчасти Doosan Daewoo COOLER(2) BODY PARTS

-

4920-1036A

COOLER ASS'Y

SERIAL: 151

-2шт.

1

2920-6010A

COOLER UNIT

desc: REFRIGERATION

1шт.

2

2208-6006A

COMPRESSOR

desc: ENSEMBLE COMPRESSEUR

1шт.

3

S2211361

BOLT;SOCKET M12X1.5X35

desc: BOULON A 6 PANS CREUX

3шт.

4

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

3шт.

5

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE M10

3шт.

6

S0509003

BOLT M8X1.25X25

desc: BOULON A 6 PANS

9шт.

7

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

9шт.

8

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

9шт.

9

4185-1346

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

10

2204-6017

DRIER;RECEIVER

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

11

2514-6001

HOLDER;DRIER

desc: RESERVOIR DESSICATEUR

1шт.

12

4195-2831

BRACKET;R/D HOLDER

desc: SUPPORT

1шт.

13

2520-6002

CONDENSOR

desc: SUPPORT

1шт.

14

S0553551

BOLT M6X1.0

SERIAL: 151-159

4шт.

14

S0553853

BOLT M6X1.0

SERIAL: 160

4шт.

15

S5100303

WASHER;SPRING M6

SERIAL: 151-159

10шт.

15

S5100303

WASHER;SPRING M6

SERIAL: 160

9шт.

16

S5010313

WASHER;PLAIN M6

SERIAL: 151-159

10шт.

16

S5010313

WASHER;PLAIN M6

SERIAL: 160

9шт.

17

S4012303

NUT M6X1.0

desc: ECROU

6шт.

18

S0504803

BOLT M6X1.0X20

desc: BOULON A 6 PANS

4шт.

19

2185-1343D6

HOSE;LIQUID(1) 2300L

desc: TUYAU FLEXIBLE

1шт.

20

2185-1249D8

HOSE;LIQUID(2) 4000L

desc: TUYAU FLEXIBLE

1шт.

21

4197-1075

BRACKET;LOWER

desc: SUPPORT

1шт.

22

4197-1076

BRACKET;UPPER

desc: SUPPORT

1шт.

23

4621-3092

COVER;SWITCH

desc: COUVERCLE

1шт.

24

2920-6102

FAN;CONDENSOR

desc: VENTILATEUR

1шт.

25

4161-2017

RUBBER NBR

SERIAL: 151-169

2шт.

25

4161-2091

RUBBER NBR

SERIAL: 170

2шт.

26

4161-2016

RUBBER NBR

desc: FAISCEAU COMPRESSEUR

1шт.

27

S3450553

SCREW M4

SERIAL: 109

4шт.

28

2549-1132D3

SWITC;BLOWER

SERIAL: 109

1шт.

29

2549-1132D2

SWITCH;AIRCON

SERIAL: 109

1шт.

30

2530-1264B

HARNESS;COMPRESSOR

desc: FAISCEAU COMPRESSEUR

1шт.

31

4621-3093

COVER SS41. L.6T

desc: COUVERCLE

1шт.

32

4197-1078

BRACKET

SERIAL: 151-159

2шт.

32

4197-1078A

BRACKET

SERIAL: 160

2шт.

33

S0715053

BOLT M12X1.25X25

desc: BOULON A 6 PANS

2шт.

34

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

2шт.

35

S5010713

WASHER;PLAIN M12

desc: RONDELLE M12

2шт.

36

S0505253

BOLT M6X30

desc: BOULON A 6 PANS

1шт.

37

2544-9020

RELAY;CONDENSOR FAN

desc: RELAIS

1шт.

38

S3450823

SCREW M5

desc: VIS

1шт.

39

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

1шт.

40

2185-6010A

HOSE;DRAIN

SERIAL: 170

1шт.
