Запчасти Doosan Daewoo COOLER(1) BODY PARTS

-

4920-1036

COOLER ASS'Y

SERIAL: 1-150

-2шт.

1

4920-9023

COOLER

desc: REFRIGERATION

1шт.

1A

4920-6024

EVAPORATOR

SERIAL: 1-7

1шт.

1A

4920-6024A

EVAPORATOR

SERIAL: 8

1шт.

1B

2208-6006

COMPRESSOR

ICA: Y

1шт.

1B

2208-6006A

COMPRESSOR

desc: . ENSEMBLE COMPRESSEUR

1шт.

1C

S2212261

BOLT;SOCKET M10X1.5X30

desc: . BOULON A 6 PANS CREUX M10X1.5X3

3шт.

1D

S5110601

WASHER;SPRING M10

desc: . RONDELLE ELASTIQUE M10

3шт.

1E

S5020603

WASHER;PLAIN M10

desc: . RONDELLE PLATE M10

3шт.

1F

S0509003

BOLT M8X1.25X25

desc: . BOULON A 6 PANS

2шт.

1G

S5102503

WASHER;SPRING M8

desc: . RONDELLE ELASTIQUE M8

2шт.

1H

S5010513

WASHER;PLAIN M8

desc: . RONDELLE M8

2шт.

1I

4185-1291

HOSE;COMPRESSOR

SERIAL: 1-22

1шт.

1I

4185-1346

HOSE;COMPRESSOR

SERIAL: 23

1шт.

1J

2204-6017

DRIER;RECEIVER

desc: . RESERVOIR DESSICATEUR

1шт.

1K

2514-6001

HOLDER;DRIER

desc: . CUVETTE DE FUSIBLE

1шт.

1L

4195-2831

BRACKET;DRIERHOLDER

desc: . SUPPORT

1шт.

1M

S0509003

BOLT M8X1.25X25

desc: . BOULON A 6 PANS

2шт.

1N

S5102503

WASHER;SPRING M8

desc: . RONDELLE ELASTIQUE M8

2шт.

1O

S5010513

WASHER;PLAIN M8

desc: . RONDELLE M8

2шт.

1P

4195-3008

BRACKET

desc: . SUPPORT

2шт.

1Q

2520-6002

CONDENSER

desc: . CONDENSEUR

1шт.

1R

-

BOLT M6X1.0X45

desc: . BOULON A 6 PANS

4шт.

1S

S5100303

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE M6

10шт.

1T

S5010313

WASHER;PLAIN M6

desc: . RONDELLE M6

10шт.

1U

S4012303

NUT M6X1.0

desc: . ECROU M6X1.0

6шт.

1V

S0504803

BOLT M6X1.0X20

desc: . BOULON A 6 PANS

6шт.

1W

2185-1249D10

HOSE;LIQUID 2500L

desc: . TUYAU FLEXIBLE

1шт.

1X

2185-1249D8

HOSE;LIQUID 4000L

desc: . TUYAU FLEXIBLE

1шт.

2

2530-1264B

HARNESS;COMPRESSOR

desc: FAISCEAU COMPRESSEUR

1шт.

3

2160-1227D5

BUSHING;RUBBER

SERIAL: 109

1шт.

4

2160-1227D2

BUSHING;RUBBER

SERIAL: 109

1шт.

5

2124-1084D2

CLIP;BAND

SERIAL: 109

2шт.
