Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

920-00060

COOLER & HEATER ASS'Y

SC: D

-2шт.

15

185-00010

HOSE;DISCHARGE 3200L

desc: TUYAU FLEXIBLE

1шт.

15A

2180-6089

O-RING(COND) D10.77X1.78T

desc: . JOINT TORIQUE

1шт.

15B

2180-6088

O-RING(COMP) D10.8X2.4T

desc: . JOINT TORIQUE

1шт.

15C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

16

185-00011

HOSE;SUCTION 3600L

desc: TUYAU FLEXIBLE

1шт.

16A

2180-6086

O-RING(COMP) D13.4X2.4T

desc: . JOINT TORIQUE

1шт.

16B

2180-6087

O-RING(EVA) D13.9X1.78T

desc: . JOINT TORIQUE

1шт.

16C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

17

2520-6004

CONDENSER ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

17A

2520-6005

CORE;CONDENSER

desc: . NOYAU

1шт.

17B

2538-6018

FAN MOTOR ASS'Y 24V

desc: . MOTEUR

1шт.

17C

2520-6006

NET;CONDENSER

desc: . ENSEMBLE COMPRESSEUR

1шт.

18

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

6шт.

19

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

6шт.

20

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

6шт.

21

195-00140

BRACKET;CONDENSER

desc: SUPPORT

2шт.

22

S0558553

BOLT M10X1.5X50

desc: BOULON A 6 PANS

4шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

24

2114-1058D1

WASHER

desc: RONDELLE

4шт.

25

2512-1077

RUBBER;CUSHION

desc: CAOUTCHOUC

8шт.

26

2185-1697D1

HOSE;LIQUID(1) 610L

desc: TUYAU FLEXIBLE

1шт.

26A

2180-6090

O-RING D6.07X178T

desc: . JOINT TORIQUE

2шт.

27

4185-1775D3

HOSE;LIQUID(2) 2400L

desc: TUYAU FLEXIBLE

1шт.

27A

2180-6090

O-RING D6.07X1.78T

desc: . JOINT TORIQUE

2шт.

28

2204-6039A

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

29

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

30

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

32

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

33

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

34

2114-1058D29

WASHER D26XD9

desc: RONDELLE

6шт.

40

124-00199D1

CLIP D20X2/M8

desc: ATTACHE

6шт.

41

2121-1305

NUT M8X1.25

desc: ECROU

4шт.

42

2124-1622D3

CLIP;BAND 280L

desc: ATTACHE

5шт.
