Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01304-0023C

CASE;TIMING GEAR

desc: CAS DE VITESSE DE SYNCHRONISATION

1шт.

2

65.91010-0017

PIN;DOWEL M6X60

desc: GOUPILLE D'AJUSTAGE

2шт.

3

65.01903-0048B

GASKET

desc: JOINT

1шт.

4

06.01943-3317

BOLT ASS'Y M12X1.5X30

desc: BOULON A 6PANS

3шт.

5

06.01943-3320

BOLT ASS'Y M12X1.5X45

desc: BOULON A 6PANS

5шт.

6

06.01913-3215

BOLT ASS'Y M10X25

desc: BOULON A 6PANS

1шт.

7

65.01305-5049G

T.G.C. COVER ASS'Y

desc: COUVERCLE

1шт.

8

65.01903-0050

GASKET;T.G.C. COVER

desc: COUSSINET COTE STD

1шт.

9

06.01923-2914

BOLT ASS'Y M6X22

desc: BOULON A 6PANS

6шт.

10

06.01923-2917

BOLT ASS'Y M6X30

desc: BOULON A 6PANS

7шт.

11

06.01953-3326

BOLT ASS'Y M12X1.5X75

desc: BOULON A 6PANS

3шт.

12

65.01510-0157

SEAL;OIL

desc: JOINT

1шт.

21

60.91601-0010

COVER

desc: COUVERCLE

1шт.

22

65.47901-0010

GASKET;P/S PUMP

desc: PALIER

1шт.

23

06.01913-3219

BOLT ASS'Y M10X40

desc: BOULON A 6PANS

2шт.

24

06.01013-9221

BOLT;HEX M10X80

desc: BOULON A 6PANS

1шт.

25

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

31

65.91601-0003

COVER;BLIND

SERIAL: 040325

1шт.

31

65.91601-6003

COVER;BLIND

SERIAL: 040715

1шт.

31

65.91601-6003A

COVER;BLIND

SERIAL: 040716

1шт.

32

06.01924-3217

BOLT ASS'Y

desc: BOULON A 6PANS

4шт.

33

65.54901-0025A

GASKET;AIR COMPRESSOR

desc: PALIER

1шт.

34

65.05701-5361

OIL PIPE ASS'Y

desc: CONDUITE

1шт.

35

65.97401-0152

CLIP;PIPE

desc: ATTACHE

1шт.

36

06.01913-2910

BOLT;HEX M6X12

desc: BOULON A 6 PANS

1шт.

37

06.11063-8212

NUT;HEX M6

desc: ECROU

1шт.

38

65.98150-0056

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

39

06.56180-0712

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.
