Запчасти Doosan Daewoo INTAKE MANIFOLD ENGINE PARTS
14
16
15
17
11
5
7
8
10
13
18
4
7
12
9
13
19
20
21
21
20
19
3
1
6
2
7
8
1
65.08201-5057
MANIFOLD;INTAKE
desc: TUBULURE ET COLLECTEUR
1шт.
2
65.08902-0025
GASKET;INTAKE MANIFOLD
desc: BOULON A 6 PANS
1шт.
3
06.01923-3218
BOLT ASS'Y M10X35
desc: BOULON A 6PANS
8шт.
4
06.01913-3234
BOLT ASS'Y M10X130
desc: BOULON A 6PANS
1шт.
5
06.01013-9221
BOLT;HEX M10X80
desc: BOULON A 6PANS
1шт.
6
06.11063-8215
NUT;HEX M10
desc: ECROU
2шт.
7
06.16731-2108
WASHER;SPRING
desc: RONDELLE
3шт.
8
06.15010-2312
WASHER;PLAIN
desc: RONDELLE
4шт.
9
65.91701-0470
SPACER(92mm)
desc: BAGUE D'ECARTEMENT
1шт.
10
65.91701-0533
SPACER(44mm)
desc: BAGUE D'ECARTEMENT
1шт.
11
65.08202-5053
STAKE;INTAKE
SERIAL: 011224
1шт.
11
65.08202-5053A
STAKE;INTAKE
SERIAL: 011225
1шт.
12
65.26803-7028
HEATER;AIR
SERIAL: 040128
1шт.
12
65.26803-7028A
HEATER;AIR
SERIAL: 041213
1шт.
12
65.26803-7028B
HEATER;AIR
SERIAL: 041214
1шт.
13
65.09904-0008
GASKET;AIR PIPE
desc: ELEMENT FILTRE
2шт.
14
06.01013-9128
BOLT;HEX. M8X130
desc: BOULON A 6PANS
2шт.
15
06.01013-9127
BOLT;HEX. M8X120
desc: BOULON A 6PANS
2шт.
16
06.16731-2107
WASHER;SPRING
desc: RONDELLE ELASTIQUE
4шт.
17
06.15010-2311
WASHER
desc: RONDELLE
4шт.
18
65.08240-0019
BRACKET;INTAKE STAKE
desc: SUPPORT
1шт.
19
06.01733-4309
BOLT;HEX. M12X1.5X25
desc: BOULON A 6PANS
4шт.
20
06.16731-2109
WASHER;SPRING
desc: RONDELLE ELASTIQUE
4шт.
21
06.15010-2313
WASHER;PLAIN
desc: RONDELLE
4шт.
