Запчасти Doosan Daewoo INJECTION PUMP DRIVE ENGINE PARTS

1

65.11301-7010F

INJECTION DRIVE ASS'Y

SERIAL: 051102

1шт.

1

65.11301-7010G

INJECTION DRIVE ASS'Y

SERIAL: 051103

1шт.

2

65.11309-0007A

HOUSING;INJECTION DRIVE

SC: D

1шт.

3

06.32092-0307

BEARING;TAPER ROLLER

desc: . ROULEMENT A ROULEAUX CONIQUES

2шт.

4

65.01510-0039

SEAL;OIL

desc: . RONDELLE D'ETANCHEITE

1шт.

5

65.11308-0001

SHIM 0.50mm

SC: R

1шт.

5

65.11308-0002

SHIM 0.20mm

SC: R

1шт.

5

65.11308-0003

SHIM 0.15mm

SC: R

1шт.

5

65.11308-0004

SHIM 0.10mm

SC: R

1шт.

9

65.11312-0007

COVER

desc: . COUVERCLE

1шт.

10

06.01913-3115

BOLT ASS'Y M8X25

desc: . BOULON A 6PANS

3шт.

11

65.11302-0009A

SHAFT

SERIAL: 051102

1шт.

11

65.11302-0009B

SHAFT

SERIAL: 051103

1шт.

12

06.29141-0215

KEY;WOODRUFF

desc: . CLAVETTE WOODRUFF

1шт.

13

65.11301-0013C

GEAR;INJECTION PUMP DRIVE

SERIAL: 051102

1шт.

13

65.11301-0013D

GEAR;INJECTION PUMP DRIVE

SERIAL: 051103

1шт.

14

06.11250-4329

NUT;HEX M24X1.5

desc: . ECROU

1шт.

15

06.16050-0316

WASHER;LOCK

desc: . RONDELLE FREIN

1шт.

16

65.11902-0017

GASKET

desc: PALIER

1шт.

17

06.01913-3218

BOLT;HEX ASS'Y M10X35

SERIAL: 021107

3шт.

17

65.90020-0079

BOLT;HEX ASS'Y M10X35

SERIAL: 021108

3шт.
