Запчасти Doosan Daewoo CRANK SHAFT & PISTON ENGINE PARTS

101

65.02101-7541A

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

101

65.02101-7541B

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

102

65.02101-7054A

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

102

65.02101-7054B

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

103

65.02101-0054

CRANKSHAFT

SERIAL: 020830

1шт.

103

65.02101-0054A

CRANKSHAFT

SERIAL: 020831

1шт.

105

65.02110-0013E

COUNTER;WEIGHT

SC: D

1шт.

107

65.02110-0014E

COUNTER;WEIGHT

SC: D

1шт.

109

65.90430-0012B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

110

65.90430-0013B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

111

65.02101-0057

CRANK SHAFT ASS'Y

SERIAL: 020830

1шт.

111

65.02101-0057A

CRANK SHAFT ASS'Y

SERIAL: 020831

1шт.

112

65.02101-0060A

CRANK SHAFT ASS'Y

desc: . ENSEMBLE VILEBREQUIN

1шт.

113

65.02115-0008B

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

115

06.22022-0912

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

1шт.

201

65.02201-7032

DAMPER VISCOUS

desc: AMORTISSEUR DE VIBRATIONS

1шт.

204

06.01914-3215

BOLT ASS'Y M10X25

SERIAL: 040701

6шт.

204

65.90020-0062B

BOLT ASS'Y M10X25

SERIAL: 040702

6шт.

301

65.02301-5102

FLY WHEEL ASS'Y

desc: VOLANT

1шт.

302

65.02301-0248

FLY WHEEL

SC: D

1шт.

304

65.02310-0011B

GEAR;STARTER RING

desc: . COURONNE DENTEE

1шт.

305

06.22022-1010

PIN;DOWEL

desc: GOUPILLE DE BLOCAGE 8x16

1шт.

306

65.90001-0164

BOLT;HEX. M14X1.5X70

desc: BOULON A 6 PANS

8шт.

307

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

401

65.02401-6012E

CONNECTING ROD ASS'Y

SERIAL: 030206

6шт.

401

65.02401-6012F

CONNECTING ROD ASS'Y

SERIAL: 041216

6шт.

401

65.02401-6012G

CONNECTING ROD ASS'Y

SERIAL: 041217

6шт.

402

65.02401-0045E

ROD;CONNECTING

SERIAL: 030206

1шт.

402

65.02401-0045F

ROD;CONNECTING

SERIAL: 041216

1шт.

402

65.02401-0045G

ROD;CONNECTING

SERIAL: 041217

1шт.

404

65.90020-0010E

BOLT

desc: . BOULON A 6 PANS

2шт.

405

65.02405-1006

BUSH

desc: . BUISSON

1шт.

406

65.91301-0010

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE

2шт.

407

65.02410-6106

METAL;CONNECTING ROD

desc: PALIER

6шт.

501

65.02501-0222

PISTON

desc: PISTON

6шт.

502

65.02503-0057

RING;TOP

SERIAL: 020528

6шт.

502

65.02503-0674

RING;TOP

SERIAL: 020529

6шт.

503

65.02503-0097

RING;2nd

desc: SEGMENT DE COMPRESSION

6шт.

504

65.02503-0105

RING;OIL

SERIAL: 020528

6шт.

504

65.02503-0675B

RING;OIL

SERIAL: 020529

6шт.

505

65.02502-0013

PIN;PISTON

desc: BROUCH

6шт.

506

06.29020-0127

RING;SNAP

desc: BAGUE

12шт.

601

65.02601-0180

PULLEY;V-BELT

desc: POULLIE

1шт.

602

65.90701-0088

WASHER;THRUST

desc: RONDELLE

1шт.

603

06.02106-0622

BOLT;SOCKET

desc: BOULON 6 PANS M10x20

8шт.
