Запчасти Doosan Daewoo ALTERNATOR & AIR COMP. MOUNTING ENGINE PARTS

201

65.19102-0075

BRACKET;ALTERNATOR MOUNTING

desc: SUPPORT

1шт.

209

65.19103-6012

EYE BOLT ASSY

desc: BOULON A 6PANS

1шт.

210

65.90435-0011

EYE BOLT

desc: . BOULON 6 PANS

1шт.

211

65.19107-0001

PIECE;GUIDE

desc: . GUIDE

1шт.

212

65.93020-0055

BUSH

desc: . COUSSINET

1шт.

213

06.11063-9217

NUT;HEX

desc: . ECROU 6 PANS

3шт.

214

06.01943-3319

BOLT ASS'Y M12X1.5X40

desc: BOULON 6 PANS

1шт.

215

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

216

06.01013-9220

BOLT;HEX. M10X1.5X75

desc: BOULON A 6 PANS

1шт.

217

06.01913-3219

BOLT ASS'Y M10X40

desc: BOULON A 6 PANS

2шт.

301

65.28652-0015

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

302

06.01943-3323

BOLT ASS'Y M12X1.5X60

desc: BOULON 6 PANS

2шт.

303

06.01913-3217

BOLT ASS'Y M10X30

desc: BOULON A 6 PANS

1шт.

309

65.19103-6012

EYE BOLT ASSY

desc: BOULON A 6PANS

1шт.

310

65.90435-0011

EYE BOLT

desc: . BOULON 6 PANS

1шт.

311

65.19107-0001

PIECE;GUIDE

desc: . GUIDE

1шт.

312

65.93020-0055

BUSH

desc: . COUSSINET

1шт.

313

06.11063-9217

NUT;HEX

desc: . ECROU 6 PANS

3шт.

314

06.01943-3319

BOLT ASS'Y M12X1.5X40

desc: BOULON 6 PANS

1шт.
