Запчасти Doosan Daewoo RADIATOR GRILL(OPT.)-FOR CCTV BODY PARTS

-

623-00027

RADIATOR GRILL

SERIAL: 1001-1130

1шт.

1

623-00026

GRILLE;RADIATOR

desc: RADIATEUR GRIL

1шт.

2

195-00357A

BRACKET

desc: SUPPORT

1шт.

3

195-00367A

BRACKET

desc: SUPPORT

1шт.

4

191-00220B

PLATE

desc: PLAQUE

1шт.

4A

2125-9054

LOCK

desc: . ENSEMBLE VERROU

1шт.

5

195-00369

BRACKET

desc: SUPPORT

1шт.

6

171-00001A

HINGE

desc: PAUMELLE

2шт.

7

S0558653

BOLT M10X1.5X55

desc: BOULON A 6 PANS

4шт.

8

S4012633

NUT M10X1.5

desc: ECROU

10шт.

9

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

8шт.

10

S5102603

WASHER;SPRING

desc: RONDELLE PLATE

10шт.

11

S0556253

BOLT M8X1.25X45

desc: BOULON A 6 PANS

7шт.

12

S4012533

NUT M8X1.25

desc: ECROU

15шт.

13

S5010513

WASHER;PLAIN

desc: RONDELLE PLATE

30шт.

14

S5102503

WASHER;SPRING

desc: RONDELLE PLATE

15шт.

15

2114-1058D10

WASHER

desc: RONDELLE PLATE

6шт.

16

621-00655B

PLATE

desc: PLAQUE

1шт.

18

S3407163

SCREW M8X1.25X45

desc: VIS

8шт.
