Запчасти Doosan Daewoo ELECTRIC PARTS(4)-BATTERY BODY PARTS

-

500-00035

ELECTRIC PARTS(2)

SC: D

-2шт.

1

506-00003

BATTERY

desc: BATTERIE

2шт.

2

2197-1119

BRACKET;BATTERY

desc: SUPPORT

1шт.

3

2120-1036D12

BOLT M10X1.5X240

desc: BOULON A 6 PANS

2шт.

4

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

5

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

2шт.

6

2544-9024

RELAY;BATTERY

desc: RELAIS BATTERIE

1шт.

7

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

8

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

9

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

10

2527-9004

BREAKER;CIRCUIT

desc: SUPPORT

1шт.

11

2120-1354

SCREW

desc: VIS

2шт.

12

2527-1023A

FUSIBLE LINK

desc: FUSIBLE

1шт.

13

2544-1022

RELAY;STARTER

desc: RELAIS DEMARREUR

1шт.

14

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

2шт.

15

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.
