Запчасти Doosan Daewoo DRIVING SYSTEM ENGINE PARTS

A
15
16
28
17
29
30
19
20
32
31
27
32
24
21
22
26
18
2
25
23
3
5
4
7
9
6
14
18
8
1
35
13
34
33
11
9
12
10

Артикул

Название

Примечание

Количество

A

65.02101-7541B

CRANKSHAFT ASS'Y

SC: D

1шт.

1

65.02101-0057A

SHAFT;CRANK

desc: . ENSEMBLE VILEBREQUIN

1шт.

2

65.02101-0060A

CRANK SHAFT ASS'Y

desc: . ENSEMBLE VILEBREQUIN

1шт.

3

65.02101-0054A

SHAFT;CRANK

SC: D

1шт.

4

65.02110-0013E

WEIGHT;COUNTER

SC: D

4шт.

5

65.02110-0014E

WEIGHT;COUNTER

SC: D

4шт.

6

65.90430-0012B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

7

65.90430-0013B

BOLT;CRANK SHAFT

desc: .. BOULON A 6 PANS

8шт.

8

65.02115-0008B

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

9

06.22022-0912

PIN;DOWEL M6X20

desc: GOUPILLE D'AJUSTAGE

1шт.

10

65.01110-6115

BEARING;MAIN

desc: PALIER

7шт.

10

65.01110-6116

BEARING;MAIN 0.25

SC: US

7шт.

10

65.01110-6117

BEARING;MAIN 0.50

SC: US

7шт.

11

65.01150-0017A

WASHER;THRUST(UP)

desc: RONDELLE DE BUTEE

2шт.

11

65.01150-0048A

WASHER;THRUST 0.25

SC: OS

2шт.

11

65.01150-0049A

WASHER;THRUST 0.50

SC: OS

2шт.

12

65.01150-0018B

WASHER;THRUST(LOW)

desc: RONDELLE DE BUTEE

2шт.

12

65.01150-0052B

WASHER;THRUST 0.25

SC: OS

2шт.

12

65.01150-0053B

WASHER;THRUST 0.50

SC: OS

2шт.

13

65.02201-7032

VISCOUS;DAMPER

desc: AMORTISSEUR DE VIBRATIONS

1шт.

14

06.01914-3215

BOLT ASS'Y M10X25

SERIAL: 040701

6шт.

14

65.90020-0062B

BOLT ASS'Y M10X20

SERIAL: 040702

6шт.

15

65.02301-5102

FLYWHEEL

desc: VOLANT

1шт.

16

65.02301-0248

FLYWHEEL

desc: . VOLANT

1шт.

17

65.02310-0011A

GEAR;STARTER RING

desc: . COURONNE DENTEE

1шт.

18

06.22022-1010

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

1шт.

19

65.90001-0164

BOLT;HEX. M14X1.5X70

desc: BOULON A 6 PANS

8шт.

20

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

21

65.02401-6017A

CONNECTING ROD ASS'Y

SERIAL: 041216

6шт.

21

65.02401-6017B

CONNECTING ROD ASS'Y

SERIAL: 060628

6шт.

21

65.02401-6017C

CONNECTING ROD ASS'Y

SERIAL: 060629

6шт.

22

65.02401-0045F

ROD;CONNECTING

SERIAL: 041216

1шт.

22

65.02401-0045G

ROD;CONNECTING

SERIAL: 041217

1шт.

23

65.90020-0010E

BOLT;CON-ROD

desc: . BOULON A 6PANS

2шт.

24

65.02405-1010

BUSH;CON-ROD

SERIAL: 060628

1шт.

24

65.02405-0011

BUSH;CON-ROD

SERIAL: 060629

1шт.

25

65.91301-0010

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE

2шт.

26

65.02410-6106

BEARING;CON-ROD

desc: PALIER

6шт.

26

65.02410-6107

BEARING;CON-ROD 0.25

SC: US

6шт.

26

65.02410-6108

BEARING;CON-ROD 0.50

SC: US

6шт.

26

65.02410-6109

BEARING;CON-ROD 0.75

SC: US

6шт.

27

65.02501-0601

PISTON

SERIAL: 050708

6шт.

27

65.02501-0601A

PISTON

SERIAL: 061011

6шт.

27

65.02501-0601B

PISTON

SERIAL: 061011

6шт.

28

65.02503-0674

RING;TOP

desc: BAGUE

6шт.

29

65.02503-0097

RING;2ND

desc: SEGMENT DE COMPRESSION

6шт.

30

65.02503-0675B

RING;PISTON

desc: BAGUE D'ETANCHEITE

6шт.

31

65.02502-0013

PIN;PISTON

desc: AXE DE PISTON

6шт.

32

06.29020-0127

RING;SNAP 45X1.75

desc: BAGUE

12шт.

33

65.02601-0180

PULLEY;V-BELT

desc: POULIE

1шт.

34

65.90701-0088

WASHER

desc: RONDELLE

1шт.

35

06.02106-0622

BOLT;SOCKET HEAD

desc: BOULON DE PLOT

8шт.

Выбрано товаров: 52
