Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

1

65.01101-6213B

CYLINDER BLOCK ASS'Y

SERIAL: 040213

1шт.

1

65.01101-6213D

CYLINDER BLOCK ASS'Y

SERIAL: 051201

1шт.

1

65.01101-6213E

CYLINDER BLOCK ASS'Y

SERIAL: 051202

1шт.

2

65.01101-0212A

BLOCK;CYLINDER

SERIAL: 051201

1шт.

2

65.01101-0212B

BLOCK;CYLINDER

SERIAL: 051202

1шт.

3

65.04410-0016

BUSH;CAM SHAFT

SC: B

4шт.

4

65.90302-0048

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE

6шт.

5

06.15091-0326

PLUG;CORE

SERIAL: 040213

15шт.

5

65.91606-0037

PLUG;CORE

SERIAL: 040214

15шт.

6

65.01105-1177B

BEARING;CAP NO.2.6

SC: D

3шт.

7

65.01105-1180B

BEARING;CAP

SC: D

2шт.

8

65.01105-1179C

BEARING;CAP NO.1

SC: D

1шт.

9

65.01105-1178B

CAP BEARING;THRUST

SC: D

1шт.

10

65.90020-0036B

BOLT;BEARING CAP

desc: . BOULON A 6PANS

14шт.

11

65.91710-0035B

RING;LOCATING

desc: . BAGUE DE CENTRAGE

14шт.

12

65.91606-0041

PLUG;CORE HOLE

desc: BOUCHON

2шт.

13

65.90310-0137

SCREW;PLUG M16X1.5X20

desc: BAGUE D'ETANCHEITE A16X20

1шт.

14

06.56190-0708

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

1шт.

15

65.90310-0136

SCREW;PLUG

SERIAL: 040421

1шт.

15

65.90310-0136A

SCREW;PLUG

SERIAL: 040422

1шт.

16

06.56190-0718

RING;SEAL

desc: BAGUE

1шт.

17

06.08092-2403

SCREW;PLUG M12X1.5

desc: BAGUE D'ETANCHEITE A16X20

1шт.

18

06.56190-0703

RING;SEAL

desc: VIS

1шт.

19

65.90310-0131

SCREW;PLUG

desc: VIS

1шт.

20

06.56190-0712

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

21

65.90310-0149A

SCREW;PLUG M26X1.5

desc: VIS

1шт.

22

06.56190-0726

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

23

65.01201-0072

LINER;CYLINDER

SERIAL: 040706

6шт.

23

65.01201-0072A

LINER;CYLINDER

SERIAL: 040707

6шт.

24

65.01601-6006

OIL SPRAY NOZZLE(NO.1. 4. 5)

desc: BEC

3шт.

25

65.01601-6007

OIL SPRAY NOZZLE(NO.2. 3. 6)

desc: BEC

3шт.

26

65.90001-0126

BOLT;HEX

desc: BOULON A 6 PANS

12шт.

27

06.16044-0208

WASHER;SPRING

desc: RONDELLE PLATE

12шт.

28

65.05405-7021

RELIEF VALVE ASS'Y

desc: VANNE

1шт.

29

06.56190-0704

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

1шт.
