Запчасти Doosan Daewoo WATER PUMP ENGINE PARTS

1

65.06500-6157D

WATER PUMP ASS'Y

SERIAL: 040325

1шт.

1

65.06500-6357

WATER PUMP ASS'Y

SERIAL: 040715

1шт.

1

65.06500-6357A

WATER PUMP ASS'Y

SERIAL: 040716

1шт.

2

65.06501-0077C

HOUSING;WATER PUMP

SERIAL: 040325

1шт.

2

65.06501-0092

HOUSING;WATER PUMP

SERIAL: 040326

1шт.

3

65.06301-0673

PIPE;COOLING WATER

SC: D

1шт.

4

65.06505-0041

SHAFT

SERIAL: 040325

1шт.

4

65.06505-0026

SHAFT

SERIAL: 040715

1шт.

4

65.06505-0027

SHAFT

SERIAL: 040716

1шт.

5

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

6

65.06506-0024A

IMPELLER

SERIAL: 040325

1шт.

6

65.06506-0027

IMPELLER

SERIAL: 040326

1шт.

7

65.01510-0103

SEAL;OIL

desc: . JOINT D'HUILE

1шт.

8

06.31420-4513

BEARING;BALL

desc: . PALIER

1шт.

9

65.06508-0012

SPACER

desc: . PALIER

1шт.

10

65.93410-0038

BEARING

desc: . PALIER

1шт.

11

06.29020-0131

RING;SNAP;RING 52X2

desc: . CIRCLIP

1шт.

12

65.06507-0005A

GEAR;WATER PUMP DRIVE

desc: . PIGNON

1шт.

13

65.06901-0076

GASKET

desc: . RONDELLE DE BUTEE

1шт.

14

65.06512-0014

COVER

desc: . COUVERCLE

1шт.

15

06.01913-2914

BOLT ASS'Y M6X22

desc: . BOULON A 6PANS

5шт.

16

65.96501-0068

O-RING

desc: JONT TORIQUE

1шт.

17

06.01913-3234

BOLT ASS'Y M10X130

desc: BOULON A 6PANS

4шт.
