1
65.04101-0050A
VALVE;INTAKE
desc: VANNE
6шт.
2
65.04101-0044
VALVE;EXHAUST
desc: VANNE
6шт.
3
65.04102-6004A
SPRING ASS'Y(EXHAUST)
desc: JOINT TORIQUE
6шт.
4
65.04102-0066
SPRING;VALVE(OUTER)
desc: . RESSORT DE EXTERIEUR SOUPAPE
1шт.
5
65.04102-0002A
SPRING;VALVE(INNER)
desc: . RESSORT DE INTERIEUR SOUPAPE
1шт.
6
65.04102-0066
SPRING;VALVE(OUTER)
desc: RESSORT DE EXTERIEUR SOUPAPE
6шт.
7
65.04103-0014
RETAINER;VALVE SPRING
desc: COUPELLE DE RESSORT DE SOUPAPE
12шт.
8
65.04103-0078
SEAT;VALVE SPRING
desc: SIEGE
12шт.
9
65.04104-0007
COTTER;VALVE
desc: CLAVETTE DE SOUPAPE
24шт.
10
65.04902-0010
SEAL;VALVE STEM
desc: JOINT
12шт.
11
65.04200-6027C
R/ARM & SHAFT ASS'Y
SERIAL: 060621
2шт.
11
65.04200-6027D
R/ARM & SHAFT ASS'Y
SERIAL: 060622
2шт.
12
65.04201-5014E
ROCKER ARM ASS'Y
desc: . AXE DE CULBUTEUR
6шт.
15
65.04203-5010
SHAFT;ROCKER ARM
desc: . AXE DE CULBUTEUR
1шт.
16
65.97601-0104
SPRING;COMP
desc: . RESSORT
2шт.
17
65.97601-0053
SPRING;COMP(OUTER)
desc: . RESSORT
2шт.
18
65.90710-0039
WASHER;ROCKER ARM
desc: . RONDELLE D'AXE DE CULBUTEURS
2шт.
19
06.29010-0120
RING;SNAP
desc: . CIRCLIP
2шт.
20
65.04205-0003
BOLT;ADJUSTING
SERIAL: 060621
6шт.
20
65.04205-0003A
BOLT;ADJUSTING
SERIAL: 060622
6шт.
21
65.90501-0003
NUT;HEX M10X1.0
desc: . ECROU 6 PANS
6шт.
22
65.04202-0014A
BRACKET;ROCKER ARM
desc: . SUPPORT
3шт.
23
06.01283-7112
BOLT;HEX M8X18
desc: . BOULON A 6PANS
3шт.
24
06.15010-2311
WASHER
desc: . RONDELLE
3шт.
25
06.01013-9221
BOLT;HEX M10X80
desc: BOULON A 6 PANS
6шт.
26
06.16731-2108
WASHER;SPRING
desc: RONDELLE
6шт.
27
65.04301-0006
TAPPET
desc: POUSSOIR DE TIGE DE CULBUTEUR
12шт.
28
65.04302-5011
ROD;PUSH
desc: TIGE DE POUSSOIR
12шт.
29
65.04401-0489B
CAM;SHAFT
SERIAL: 040827
1шт.
29
65.04401-0489D
CAM;SHAFT
SERIAL: 040828
1шт.
30
65.98112-0038
FLANGE
desc: BRIDE
1шт.
31
65.90001-6003
BOLT ASS'Y M6X14
desc: BOULON A 6PANS
2шт.
32
06.22022-1014
PIN;DOWEL
desc: GOUPILLE D'AJUSTAGE
1шт.
34
65.04501-0007A
GEAR;CAMSHAFT
desc: PIGNON
1шт.
35
06.01914-3119
BOLT ASS'Y
desc: BOULON A 6PANS
4шт.
36
65.04505-5016
IDLE GEAR ASS'Y
desc: PIGNON
1шт.
37
65.04505-0033
GEAR;IDLE
SC: D
1шт.
38
65.04507-0004
BUSH;IDLE GEAR
SC: D
1шт.
39
65.04506-0033
PIN;IDLE GEAR
desc: GOUPILLE DE PIGNON FOU
1шт.
40
65.90720-0018
WASHER;THRUST
desc: RONDELLE DE BUTEE
1шт.
41
06.01015-9220
BOLT;HEX
desc: BOULON A 6 PANS
2шт.
42
06.16731-2108
WASHER;SPRING
desc: RONDELLE
2шт.
