Запчасти Doosan Daewoo TIMING SYSTEM ENGINE PARTS

25
25
26
26
21
12
15
23
16
24
12
9
20
7
6
4
3
11
22
5
17
10
18
28
8
19
1
36
2
39
38
37
27
29
40
42
41
30
34
35
32
31

Артикул

Название

Примечание

Количество

1

65.04101-0050A

VALVE;INTAKE

desc: VANNE

6шт.

2

65.04101-0044

VALVE;EXHAUST

desc: VANNE

6шт.

3

65.04102-6004A

SPRING ASS'Y(EXHAUST)

desc: JOINT TORIQUE

6шт.

4

65.04102-0066

SPRING;VALVE(OUTER)

desc: . RESSORT DE EXTERIEUR SOUPAPE

1шт.

5

65.04102-0002A

SPRING;VALVE(INNER)

desc: . RESSORT DE INTERIEUR SOUPAPE

1шт.

6

65.04102-0066

SPRING;VALVE(OUTER)

desc: RESSORT DE EXTERIEUR SOUPAPE

6шт.

7

65.04103-0014

RETAINER;VALVE SPRING

desc: COUPELLE DE RESSORT DE SOUPAPE

12шт.

8

65.04103-0078

SEAT;VALVE SPRING

desc: SIEGE

12шт.

9

65.04104-0007

COTTER;VALVE

desc: CLAVETTE DE SOUPAPE

24шт.

10

65.04902-0010

SEAL;VALVE STEM

desc: JOINT

12шт.

11

65.04200-6027C

R/ARM & SHAFT ASS'Y

SERIAL: 060621

2шт.

11

65.04200-6027D

R/ARM & SHAFT ASS'Y

SERIAL: 060622

2шт.

12

65.04201-5014E

ROCKER ARM ASS'Y

desc: . AXE DE CULBUTEUR

6шт.

15

65.04203-5010

SHAFT;ROCKER ARM

desc: . AXE DE CULBUTEUR

1шт.

16

65.97601-0104

SPRING;COMP

desc: . RESSORT

2шт.

17

65.97601-0053

SPRING;COMP(OUTER)

desc: . RESSORT

2шт.

18

65.90710-0039

WASHER;ROCKER ARM

desc: . RONDELLE D'AXE DE CULBUTEURS

2шт.

19

06.29010-0120

RING;SNAP

desc: . CIRCLIP

2шт.

20

65.04205-0003

BOLT;ADJUSTING

SERIAL: 060621

6шт.

20

65.04205-0003A

BOLT;ADJUSTING

SERIAL: 060622

6шт.

21

65.90501-0003

NUT;HEX M10X1.0

desc: . ECROU 6 PANS

6шт.

22

65.04202-0014A

BRACKET;ROCKER ARM

desc: . SUPPORT

3шт.

23

06.01283-7112

BOLT;HEX M8X18

desc: . BOULON A 6PANS

3шт.

24

06.15010-2311

WASHER

desc: . RONDELLE

3шт.

25

06.01013-9221

BOLT;HEX M10X80

desc: BOULON A 6 PANS

6шт.

26

06.16731-2108

WASHER;SPRING

desc: RONDELLE

6шт.

27

65.04301-0006

TAPPET

desc: POUSSOIR DE TIGE DE CULBUTEUR

12шт.

28

65.04302-5011

ROD;PUSH

desc: TIGE DE POUSSOIR

12шт.

29

65.04401-0489B

CAM;SHAFT

SERIAL: 040827

1шт.

29

65.04401-0489D

CAM;SHAFT

SERIAL: 040828

1шт.

30

65.98112-0038

FLANGE

desc: BRIDE

1шт.

31

65.90001-6003

BOLT ASS'Y M6X14

desc: BOULON A 6PANS

2шт.

32

06.22022-1014

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

1шт.

34

65.04501-0007A

GEAR;CAMSHAFT

desc: PIGNON

1шт.

35

06.01914-3119

BOLT ASS'Y

desc: BOULON A 6PANS

4шт.

36

65.04505-5016

IDLE GEAR ASS'Y

desc: PIGNON

1шт.

37

65.04505-0033

GEAR;IDLE

SC: D

1шт.

38

65.04507-0004

BUSH;IDLE GEAR

SC: D

1шт.

39

65.04506-0033

PIN;IDLE GEAR

desc: GOUPILLE DE PIGNON FOU

1шт.

40

65.90720-0018

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

41

06.01015-9220

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

42

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

Выбрано товаров: 42
