Запчасти Doosan Daewoo COUNTER WEIGHT & BATTERY BOX BODY PARTS

-

600-00036

REAR END ASS'Y

SC: D

-2шт.

1

624-00037B

WEIGHT;COUNTER

desc: CONTRE- POIDS

1шт.

2

2120-2107

BOLT M39X3.0X200

SERIAL: 3001-3058

4шт.

2

DS0002262

BOLT M39X3.0X200

SERIAL: 3059

4шт.

3

4114-1999

WASHER;HARD

SERIAL: 3001-3058

4шт.

3

4114-1999A

WASHER;HARD

SERIAL: 3059

4шт.

4

123-00045

PIN

desc: BROCHE

1шт.

5

124-00017

CLIP

desc: ATTACHE

1шт.

6

621-01061A

PLATE

desc: PLAQUE

1шт.

7

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

9шт.

8

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

9

S0565461

BOLT M16X2.0X60

desc: BOULON A 6 PANS

8шт.

10

S5010813

WASHER;PLAIN

desc: RONDELLE PLATE

8шт.

11

2160-1201D12

BUSHING;RUBBER

desc: MANCHON

1шт.

12

194-00014A

HANDRAIL;BATTERY BOX

desc: BALUSTRADE

2шт.

13

2114-1058D10

WASHER;PLAIN

desc: RONDELLE PLATE

7шт.

14

625-00067

LADDER

desc: CHELLE

1шт.

15

2191-2205D13

PLATE

desc: PLAQUE D'IDENTIFICATION

4шт.

16

S0512353

BOLT M10X1.5X35

desc: BOULON A 6 PANS

8шт.

18

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

8шт.

19

S5102903

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

20

625-00061

RUNG;LADDER

desc: CHELON

1шт.

21

2160-1004D2

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.

22

199-00039G

BOX;BATTERY

desc: CADRE

1шт.

23

199-00040G

BOX;TOOL

desc: CADRE

1шт.

24

161-00228A

HANGER;STEP

desc: CINTRE

2шт.

25

160-00019

CAP;PLASTIC

desc: CHAPEAU

2шт.
