Запчасти Doosan Daewoo REAR PLANETARY GEAR HYDRAULIC PARTS

1

3198723

COVER

desc: COUVERCLE

2шт.

2

71709

GASKET

desc: JOINT

2шт.

3

3112993

PLATE;SMALL

desc: PLAQUE

2шт.

4

70311

SCREW

desc: VIS

8шт.

5

3198703

SUPPORT

desc: SUPPORT

2шт.

6

3138703

PIN

desc: BROCHE

6шт.

7

70591

PLUG

desc: BOUCHON

2шт.

8

3112283

NUT

desc: ECROU

38шт.

9

3130043

SHIM;THRUST PLATE 1.5mm

desc: BUTEE

6шт.

10

3127393

BEARING

desc: PALIER

6шт.

11

3121773

SPACER

desc: BAGUE D'ECARTEMENT

6шт.

12

3121673

GEAR;DIFFETRENTIAL PINIO

desc: ENGRENAGE

6шт.

13

3127363

SHIM;THRUST PLATE 3.00mm

desc: BUTEE

6шт.

14

3121683

GEAR;DIFFERENTIAL SIDE

desc: ENGRENAGE

2шт.

15

70201

RING;SNAP

desc: BAGUE

2шт.

16

3138633

DISK;DRUM BRAKE

desc: DISQUE

2шт.

17

3146743

DISK;BRAKE

desc: DISQUE

8шт.

18

3146823

SHIM;PRESSURE PLATE 4mm

desc: CALE

8шт.

18

3200513

SHIM;PRESSURE PLATE 4.25mm

desc: CARTOUCHE DE PRESSION

8шт.

18

3146833

SHIM;PRESSURE PLATE 4.5mm

desc: CALE

8шт.

18

3146843

SHIM;PRESSURE PLATE 5mm

desc: CARTOUCHE DE PRESSION

8шт.

19

3138243

PIN

desc: BROCHE

12шт.

20

3120843

RING;SNAP

desc: CIRCLIP

2шт.

21

3138663

PLATE;PRESSURE

desc: PLAQUE

2шт.

22

3236633

SPRING

desc: RESSORT

6шт.

23

3236623

RING

desc: BAGUE

6шт.

24

3128073

PLATE;SMALL

desc: PLAQUE

4шт.

25

3236683

NUT;ADJUSTING

desc: ECROU

2шт.

26

70576

RING;SNAP

desc: BAGUE

2шт.

27

3138623

PLATE;THRUST

desc: BUTEE

2шт.

28

70566

BEARING

desc: PALIER

2шт.

29

3232033

SUPPORT;WHEEL

desc: SUPPORT

2шт.

30

3138583

WHEEL

desc: VOLANT

2шт.

31

3224753

HUB;WHEEL

desc: MOYEU DE FIXATION

2шт.

32

3147233

BOLT;STUD

desc: BOULON A 6 PANS

38шт.

33

70568

GASKET 5.34X113.67

desc: JOINT

2шт.

34

3230793

PISTON

desc: PISTON

2шт.

35

70575

GASKET 5.34X136.5

desc: JOINT

2шт.

36

70573

BEARING

desc: PALIER

2шт.

37

71531

GASKET 170X200X17.5/21

desc: JOINT

2шт.

38

3231893

SPINDLE;WHEEL HUB COMPLETE(R.H.)

desc: BROCHE

1шт.

39

71590

BREATHER;OIL

desc: ENSEMBLE RENIFLARD

2шт.

40

70382

SCREW

desc: VIS

12шт.

41

70565

GASKET

desc: JOINT

2шт.

42

3231913

SPINDLE;WHEEL HUB COMPLETE(L.H.)

desc: BROCHE

1шт.

43

3138103

SCREW

desc: VIS

32шт.

44

70018

WASHER

desc: RONDELLE

38шт.

45

71591

COWL;GUARD

desc: GARDE

2шт.

46

3220833

GUARD

desc: GARDE

2шт.

47

71638

RING

desc: JOINT TORIQUE

6шт.

48

3236643

PIN

desc: GOUJON

6шт.

110

3198713

SUPPORT;COMPLETE

desc: SUPPORT

2шт.
