Запчасти Doosan Daewoo ARM RAISE KICK OUT FRONT PARTS

-

4715-4001

ARM RAISE KICK OUT ASS'Y

SC: D

-2шт.

1

4621-3511

PLATE

desc: PLAQUE

1шт.

2

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

2шт.

3

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

4шт.

4

S0512253

BOLT M10X1.5X30

desc: BOULON A 6 PANS

2шт.

5

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

2шт.

6

4159-4008

COVER

desc: COUVERCLE

1шт.

7

4191-4253

PLATE

desc: PLAQUE

1шт.

8

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

2шт.

9

S0509053

BOLT M8X1.25X22

desc: BOULON A 6 PANS

2шт.

10

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

2шт.

11

S4012533

NUT M8X1.25

desc: ECROU

2шт.

12

4191-4250

PLATE

desc: PLAQUE

1шт.

13

4549-1148

SWITCH;PROXIMITY

desc: INTERRUPTEUR

1шт.
