Запчасти Doosan Daewoo RETURN TO DIG FRONT PARTS

-

4704-1499

RETURN TO DIG ASS'Y

SC: D

-2шт.

1

4192-1058

ANGLE

desc: ANGLE

1шт.

2

S0512553

BOLT M10X1.5X45

desc: BOULON A 6 PANS

4шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

4

S4012633

NUT M10

desc: ECROU M10X1.5

4шт.

5

4191-4248

PLATE

desc: PLAQUE

1шт.

6

S0515453

BOLT M12X1.75X40

desc: BOULON

2шт.

7

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

2шт.

8

4159-4008

COVER

desc: COUVERCLE

1шт.

9

S0508953

BOLT M8X1.25X22

desc: BOULON A 6 PANS

2шт.

10

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

2шт.

11

S4012533

NUT M8X1.25

desc: ECROU

2шт.

12

4549-1148

SWITCH;PROXIMITY

desc: INTERRUPTEUR

1шт.

13

4621-3930

COVER

desc: COUVERCLE

2шт.
