Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

101

65.03101-6053D

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 010320

1шт.

101

65.03101-6053F

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 011106

1шт.

101

65.03101-6053G

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 011107

1шт.

103

65.03101-0003D

HEAD;CYLINDER

SERIAL: 011106

1шт.

103

65.03101-0003F

HEAD;CYLINDER

SERIAL: 011107

1шт.

106

65.03205-0002

TUBE;NOZZLE

desc: . CONTUITES

3шт.

107

65.96501-0069

O-RING

desc: . JOINT TORIQUE

3шт.

108

65.90302-0041

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 28

6шт.

109

65.90302-0048

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 25

3шт.

110

65.90302-0042

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 32

2шт.

111

65.03201-1008E

GUIDE;VALVE

SC: B

6шт.

113

65.03203-1042

SEAT;VALVE(EXHAUST)

SC: B

3шт.

114

65.03203-1041

SEAT;VALVE(INTAKE)

SC: B

3шт.

115

65.90302-0049

PLUG;CORE

desc: . BOUCHON

3шт.

102

65.03101-6054D

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 010320

1шт.

102

65.03101-6054F

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 010321

1шт.

104

65.03101-0004D

HEAD;CYLINDER

SC: D

1шт.

106

65.03205-0002

TUBE;NOZZLE

desc: . CONTUITES

3шт.

107

65.96501-0069

O-RING

desc: . JOINT TORIQUE

3шт.

108

65.90302-0041

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 28

6шт.

109

65.90302-0048

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 25

3шт.

110

65.90302-0042

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 32

2шт.

111

65.03201-1008E

GUIDE;VALVE

SC: B

6шт.

113

65.03203-1042

SEAT;VALVE(EXHAUST)

SC: B

3шт.

114

65.03203-1041

SEAT;VALVE(INTAKE)

SC: B

3шт.

115

65.90302-0049

PLUG;CORE

desc: . BOUCHON

3шт.

116

65.03901-0053

GASKET;HEAD(FRONT)

SERIAL: 010110

1шт.

116

65.03901-0063

GASKET;HEAD(FRONT)

SERIAL: 010111

1шт.

117

65.03901-0054

GASKET;HEAD(REAR)

SERIAL: 010110

1шт.

117

65.03901-0064

GASKET;HEAD(REAR)

SERIAL: 010111

1шт.

118

65.91001-0002

PLUG

SERIAL: 001024

2шт.

118

65.91001-0013

AVSEAL

SERIAL: 001025

2шт.

119

06.22022-0907

PIN;DOWEL

desc: GOUPILLE D'AJUSTAGE

4шт.

120

65.90020-0034A

BOLT;CYL. HEAD

SERIAL: 990315

28шт.

120

65.90020-0069

BOLT;CYL. HEAD

SERIAL: 001119

28шт.

120

65.90021-0001

BOLT;CYL. HEAD

SERIAL: 001120

28шт.

121

65.41520-0003

HANGER

desc: SUPPORT

1шт.

122

06.01913-3217

BOLT ASS'Y M10X25

desc: BOULON 6 PANS

2шт.

123

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

124

06.01734-4411

BOLT;HEX. M14X1.5X30

desc: BOULON 6 PANS

1шт.

125

65.91701-0275

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

126

06.01494-4408

BOLT;HEX. M14X1.5X45

desc: BOULON 6 PANS

1шт.

201

65.03401-6047A

CYLINDER HEAD COVER ASS'Y

SERIAL: 990420

1шт.

201

REP_PNO: 65.90020-0074

-1шт.

201

REP_PNO: 65.90701-0202

-1шт.

201

REP_PNO: 65.03905-0023

-1шт.

201

65.03401-6047B

CYLINDER HEAD COVER ASS'Y

SERIAL: 990421

1шт.

202

65.03401-0055B

COVER;CYLINDER HEAD

desc: . COUVERCLE

1шт.

203

65.03905-0020

PACKING

desc: . JOINT

1шт.

204

65.90020-0012

BOLT;CYL. HEAD COVER

SERIAL: 990524

6шт.

204

65.90020-0074

BOLT;CYL. HEAD COVER

SERIAL: 990525

6шт.

205

65.03905-0017A

GASKET

SERIAL: 990524

6шт.

205

65.03905-0023

GASKET

SERIAL: 990525

6шт.

206

65.90701-0052

WASHER

SERIAL: 990524

6шт.

206

65.90701-0202

WASHER

SERIAL: 990525

6шт.

207

65.01801-5095A

HOUSING;BREATHER

SERIAL: 001101

1шт.

207

REP_PNO: 06.01923-3113

-1шт.

207

65.01801-5099

HOUSING;BREATHER

SERIAL: 010910

1шт.

207

65.01801-5099A

HOUSING;BREATHER

SERIAL: 010911

1шт.

208

65.96501-0033B

O-RING

desc: JOINT TORIQUE

1шт.

209

65.96301-0233A

HOSE;RUBBER

desc: TUYAU

1шт.

210

06.67020-0105

CLAMP

desc: COLLIER

1шт.

211

06.01923-3111

BOLT ASS'Y M8X16

SERIAL: 001101

3шт.

211

06.01923-3113

BOLT ASS'Y M8X20

SERIAL: 001102

3шт.

212

65.97401-0164

CLIP;BREATHER HOSE

desc: COLLIER

1шт.

213

06.11063-8214

NUT;HEX

desc: ECROU 6 PANS M8

1шт.

214

06.15010-2311

WASHER

desc: RONDELLE

1шт.

215

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.
