Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

1

65.01101-6068A

CYLINDER BLOCK ASS'Y

SERIAL: 991011

1шт.

1

65.01101-6212

CYLINDER BLOCK ASS'Y

SERIAL: 991012

1шт.

2

65.01101-0212

BLOCK;CYLINDER

SC: D

1шт.

3

65.04410-0016

BUSH;CAM SHAFT

SC: B

4шт.

4

65.90302-0048

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE 25

6шт.

5

06.15091-0326

PLUG;CORE

desc: . BOUCHON DE CHEMISE D'EAU B40D

15шт.

6

65.01105-1157G

CAP;BRARING(NO. 7)

SC: D

1шт.

8

65.01105-1158F

CAP;BRARING(NO. 3.5)

SC: D

2шт.

10

65.01105-1159F

CAP;BEARING

SC: D

1шт.

12

65.01105-1161A

CAP;BRARING(NO. 1.2.6)

SC: D

3шт.

14

65.91710-0035

RING

desc: . BAGUE DE CENTRAGE

14шт.

15

65.90020-0036B

BOLT;BEARING CAP

desc: . VIS DE CHAPEAU DE PALIER

14шт.

16

65.01110-6055A

METAL;MAIN STD

desc: MTAL

7шт.

16

65.01110-6068A

METAL;MAIN 0.25

SC: US

7шт.

16

65.01110-6069A

METAL;MAIN 0.50

SC: US

7шт.

17

65.01150-0017A

WASHER;THRUST(UP) STD

desc: RONDELLE DE POUSS

2шт.

17

65.01150-0048A

WASHER;THRUST(UP) 0.25

SC: OS

2шт.

17

65.01150-0049A

WASHER;THRUST(UP) 0.50

SC: OS

2шт.

18

65.01150-0018B

WASHER;THRUST(LOW) STD

desc: RONDELLE DE POUSS

2шт.

18

65.01150-0052B

WASHER;THRUST(LOW) 0.25

SC: OS

2шт.

18

65.01150-0053B

WASHER;THRUST(LOW) 0.50

SC: OS

2шт.

19

65.91606-0041

PLUG;CORE

desc: BOUCHON

2шт.

22

65.90310-0136

SCREW;PLUG M22X1.5

desc: BOUCHON A VIS

1шт.

23

06.56190-0718

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

24

65.90310-0137

SCREW;PLUG A16X1.5

desc: VIS

1шт.

25

06.56190-0708

RING;SEAL

desc: JOINT

1шт.

26

65.90310-0131

SCREW;PLUG

desc: BOUCHON A VIS

1шт.

27

06.56190-0712

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

28

65.90310-0149A

SCREW;PLUG

desc: BOUCHON A VIS

1шт.

29

06.56190-0726

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

30

65.01201-0051

LINER;CYLINDER

desc: CHEMISE DE CYLINDRE

6шт.

36

65.01601-6002

NOZZLE;OIL SPRAY

desc: INJECTEUR D'HUILE

6шт.

42

65.90001-0126

BOLT;HEX

desc: BOULON A 6 PANS

12шт.

43

06.16044-0208

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

44

06.56190-0704

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

2шт.

45

65.98150-0002

ADAPTER;OIL PRESSURE

desc: RACCORD ADAPTATEUR

1шт.

46

65.27441-7007

SWITCH;OIL PRESSURE

desc: CONTACTEUR PRESSION D'HUILE

1шт.

47

65.05405-7021

RELIEF VALVE ASS'Y

desc: VANNE

1шт.

48

06.56190-0704

RING;SEAL

desc: BAGUE D'ETANCHEITE A16X20

1шт.
