1
65.01101-6068A
CYLINDER BLOCK ASS'Y
SERIAL: 991011
1шт.
1
65.01101-6212
CYLINDER BLOCK ASS'Y
SERIAL: 991012
1шт.
2
65.01101-0212
BLOCK;CYLINDER
SC: D
1шт.
3
65.04410-0016
BUSH;CAM SHAFT
SC: B
4шт.
4
65.90302-0048
PLUG;CORE
desc: . BOUCHON DE DESSABLAGE 25
6шт.
5
06.15091-0326
PLUG;CORE
desc: . BOUCHON DE CHEMISE D'EAU B40D
15шт.
6
65.01105-1157G
CAP;BRARING(NO. 7)
SC: D
1шт.
8
65.01105-1158F
CAP;BRARING(NO. 3.5)
SC: D
2шт.
10
65.01105-1159F
CAP;BEARING
SC: D
1шт.
12
65.01105-1161A
CAP;BRARING(NO. 1.2.6)
SC: D
3шт.
14
65.91710-0035
RING
desc: . BAGUE DE CENTRAGE
14шт.
15
65.90020-0036B
BOLT;BEARING CAP
desc: . VIS DE CHAPEAU DE PALIER
14шт.
16
65.01110-6055A
METAL;MAIN STD
desc: MTAL
7шт.
16
65.01110-6068A
METAL;MAIN 0.25
SC: US
7шт.
16
65.01110-6069A
METAL;MAIN 0.50
SC: US
7шт.
17
65.01150-0017A
WASHER;THRUST(UP) STD
desc: RONDELLE DE POUSS
2шт.
17
65.01150-0048A
WASHER;THRUST(UP) 0.25
SC: OS
2шт.
17
65.01150-0049A
WASHER;THRUST(UP) 0.50
SC: OS
2шт.
18
65.01150-0018B
WASHER;THRUST(LOW) STD
desc: RONDELLE DE POUSS
2шт.
18
65.01150-0052B
WASHER;THRUST(LOW) 0.25
SC: OS
2шт.
18
65.01150-0053B
WASHER;THRUST(LOW) 0.50
SC: OS
2шт.
19
65.91606-0041
PLUG;CORE
desc: BOUCHON
2шт.
22
65.90310-0136
SCREW;PLUG M22X1.5
desc: BOUCHON A VIS
1шт.
23
06.56190-0718
RING;SEAL
desc: BAGUE D'ETANCHEITE
1шт.
24
65.90310-0137
SCREW;PLUG A16X1.5
desc: VIS
1шт.
25
06.56190-0708
RING;SEAL
desc: JOINT
1шт.
26
65.90310-0131
SCREW;PLUG
desc: BOUCHON A VIS
1шт.
27
06.56190-0712
RING;SEAL
desc: BAGUE D'ETANCHEITE
1шт.
28
65.90310-0149A
SCREW;PLUG
desc: BOUCHON A VIS
1шт.
29
06.56190-0726
RING;SEAL
desc: BAGUE D'ETANCHEITE
1шт.
30
65.01201-0051
LINER;CYLINDER
desc: CHEMISE DE CYLINDRE
6шт.
36
65.01601-6002
NOZZLE;OIL SPRAY
desc: INJECTEUR D'HUILE
6шт.
42
65.90001-0126
BOLT;HEX
desc: BOULON A 6 PANS
12шт.
43
06.16044-0208
WASHER;SPRING
desc: RONDELLE ELASTIQUE
12шт.
44
06.56190-0704
RING;SEAL
desc: BAGUE D'ETANCHEITE A16X20
2шт.
45
65.98150-0002
ADAPTER;OIL PRESSURE
desc: RACCORD ADAPTATEUR
1шт.
46
65.27441-7007
SWITCH;OIL PRESSURE
desc: CONTACTEUR PRESSION D'HUILE
1шт.
47
65.05405-7021
RELIEF VALVE ASS'Y
desc: VANNE
1шт.
48
06.56190-0704
RING;SEAL
desc: BAGUE D'ETANCHEITE A16X20
1шт.
