Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

0

65.06500-6405B

WATER PUMP ASS'Y(1~16)

SERIAL: 990203

1шт.

0

65.06500-6157

WATER PUMP ASS'Y(1~16)

SERIAL: 000915

1шт.

0

65.06500-6157B

WATER PUMP ASS'Y(1~16)

SERIAL: 011129

1шт.

0

65.06500-6157C

WATER PUMP ASS'Y(1~16)

SERIAL: 011130

1шт.

1

65.06501-0220B

HOUSING;WATER PUMP

SERIAL: 990203

1шт.

1

65.06501-0077

HOUSING;WATER PUMP

SERIAL: 000915

1шт.

1

65.06501-0077B

HOUSING;WATER PUMP

SERIAL: 000916

1шт.

2

65.06301-0673

PIPE

SC: D

1шт.

4

65.06505-0042

SHAFT

SERIAL: 990203

1шт.

4

65.06505-0043

SHAFT

SERIAL: 000915

1шт.

4

65.06505-0041

SHAFT

SERIAL: 990204

1шт.

5

65.06520-6007

SEAL;MECHANICAL

desc: . ROULEMENT A BILLES

1шт.

6

65.06506-0024A

IMPELLER

desc: . BAGUE D'ECARTEMENT

1шт.

7

06.29170-0108

RING;SNAP

SERIAL: 990203

1шт.

8

65.93410-0083

BEARING;TAPER ROLLER

SERIAL: 990203

1шт.

8

65.93410-0038

BEARING;TAPER ROLLER

SERIAL: 990204

1шт.

9

06.31420-4513

BALL BEARING 6005U

SERIAL: 990204

1шт.

9A

65.06508-0012

SPACER

SERIAL: 990204

1шт.

10

65.01510-0155

SEAL;OIL

SERIAL: 990203

1шт.

10

65.01510-0103

SEAL;OIL

SERIAL: 990204

1шт.

11

06.29180-0118

RING;SNAP

SERIAL: 990203

1шт.

11

06.29020-0131

SNAP RING 52X2

SERIAL: 990204

1шт.

12

06.29141-0212

KEY

SERIAL: 990203

1шт.

13

65.06507-0002

GEAR;DRIVE

SERIAL: 990203

1шт.

13

65.06507-0004

GEAR;DRIVE

SERIAL: 000915

1шт.

13

65.06507-0005

GEAR;DRIVE

SERIAL: 011129

1шт.

13

65.06507-0005A

GEAR;DRIVE

SERIAL: 011130

1шт.

14

65.06901-0076

GASKET

desc: . CONDUITE

1шт.

15

65.06512-0014

COVER;WATER PUMP HSG

desc: . VILEBREQUIN

1шт.

16

06.01913-2914

BOLT ASS'Y M6Ўї22

desc: . JOINT

5шт.

17

06.15020-0306

WASHER;SPRING

SERIAL: 990203

1шт.

18

06.11034-9205

NUT;HEX

SERIAL: 990203

1шт.

19

06.01913-3234

BOLT ASS'Y M10Ўї130

desc: ROULEMENT A BILLES

4шт.

20

65.96501-0068

O-RING

desc: BAGUE D'ECARTEMENT

1шт.
