Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

0

65.06301-6054A

WATER PIPE ASS'Y(1~5)

desc: CONDUITES DE EAU

1шт.

1

65.06301-0671A

PIPE;COOLING WATER

desc: . CONDUITE

1шт.

2

65.06404-0021B

HOUSING;WATER PUMP

desc: . CARTER

1шт.

4

65.06903-0021

GASKET

desc: . JOINT

1шт.

5

06.01923-3218

BOLT M10X35

desc: . BOULON A 6 PANS

2шт.

6

65.06405-0024

PIPE. WATER OUTLET

desc: COUVERCLE

1шт.

8

51.06402-0062

THERMOSTAT

desc: THERMOSTAT

2шт.

9

06.56342-1208

O-RING

desc: JOINT TORIQUE

2шт.

10

65.06901A0069

GASKET

desc: JOINT

2шт.

11

06.01923-3124

BOLT M8X65

desc: BOULON A 6 PANS

3шт.

18

06.01923-3124

BOLT;HEX. M8X65

desc: BOULON A 6 PANS

2шт.

19

65.90201-0064

BOLT;STUD

desc: GOUJON

2шт.

20

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

21

06.15010-2311

WASHER

desc: RONDELLE

2шт.

22

06.11063-8214

NUT;HEX

desc: ECROU 6 PANS M8

2шт.

23

65.06903-0018

GASKET

desc: JOINT

2шт.

26

65.90710-0019

WASHER;PLAIN

desc: RONDELLE

1шт.

27

06.01923-3218

BOLT M10X35

desc: BOULON A 6 PANS

1шт.

28

66.27435-6008

SWITCH;WATER TEMP

desc: INTERRUPTEUR

1шт.

29

65.96301-0204A

HOSE;RUBBER

desc: TUYAU

1шт.

30

06.67020-0108

CLAMP;HOSE

desc: COLLIER

2шт.

31

65.06301-6037A

PIPE;WATER(BY-PASS)

desc: CONDUITE

1шт.

32

04.27405-1506

HOSE;RUBBER

desc: TUYAU

1шт.

33

06.67020-0108

CLAMP;HOSE

desc: COLLIER

2шт.

34

65.06301-0672

PIPE;WATER(W/P-O/C)

desc: CONDUITE

1шт.

35

06.02090-0513

BOLT;SOCKET

desc: BOULON 6 PANS M10x20

2шт.

36

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

37

06.15010-2312

WASHER

desc: RONDELLE

2шт.

38

65.06903-0020

GASKET

desc: JOINT

1шт.

39

65.96301-0205A

HOSE;RUBBER

desc: TUYAU

1шт.

40

06.67020-0110

CLAMP;HOSE

desc: COLLIER

2шт.

41

65.96301-0297

HOSE;RUBBER

desc: TUYAU

1шт.

42

06.67020-0106

CLAMP;HOSE

desc: COLLIER

4шт.

43

65.98131-0071

SCREW;CONNECTION

desc: RACCORD ADAPTATEUR

2шт.

44

06.56190-0728

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

45

65.96301-0298

HOSE;RUBBER

desc: TUYAU

1шт.

46

65.27435-6003

SWITCH;WATER TEMP

desc: MANOCONTACT DE PRESSION

1шт.
