Запчасти Doosan Daewoo ALTERNATOR & AIR COMP. MOUNTING ENGINE PARTS

1020

06.01913-3112

BOLT M8X18

desc: BOULON A 6 PANS

6шт.

1050

65.06650-6016

FAN DRIVE ASS'Y

desc: BOULON

1шт.

1100

65.19103-5035

BRACKET;ALTERNATOR SUPPORT

desc: BOULON A 6 PANS

1шт.

1110

06.01943-3332

BOLT M12X1.5X80

desc: ECROU 6 PANS

2шт.

1120

06.01013-9226

BOLT;HEX. M10X110

desc: GUIDE

2шт.

1130

06.16731-2108

WASHER;SPRING

desc: AMPOULE

2шт.

1140

65.06606-0042

PULLEY;FAN

SERIAL: 000303

1шт.

1140

REP_PNO: 65.96801-0130

-1шт.

1140

REP_PNO: 65.19103-6012

-1шт.

1140

65.06606-0022A

PULLEY;FAN

SERIAL: 000304

1шт.

1150

65.96801-0126

BELT;POLY

SERIAL: 000303

1шт.

1150

65.96801-0130

BELT;POLY

SERIAL: 000304

1шт.

2010

65.19102-0075

BRACKET.ALT

desc: BOULON 6 PANS

1шт.

2090

65.19103-6010

EYE BOLT ASS'Y(aircon.)

SERIAL: 000303

1шт.

2090

65.19103-6012

EYE BOLT ASS'Y

SERIAL: 000304

1шт.

2100

65.90441-0011

BOLT;EYE

desc: . BOULON A 6 PANS

1шт.

2110

65.19107-0001

PIECE;GUIDE

desc: . BOULON A 6 PANS

1шт.

2120

65.93020-0055

BUSH

desc: . RONDELLE

1шт.

2130

06.11063-9217

NUT;HEX. M14X1.5

desc: . ECROU 6 PANS M10

3шт.

2140

06.01943-3319

BOLT;HEX. M12X1.5X40

desc: SUPPORT

1шт.

2150

06.16731-2108

WASHER;SPRING

desc: BOULON A 6 PANS

1шт.

2160

06.01013-9220

BOLT;HEX. M10 X 75

desc: RONDELLE

1шт.

2170

06.01913-3219

BOLT M10X40

desc: BOULON A 6 PANS

2шт.

3010

65.28652-0012

BRACKET

desc: POULIE

1шт.

3020

06.01943-3323

HEX. BOLT ASS'Y M12X1.5X60

desc: BOULON 6 PANS

2шт.

3030

06.01913-3217

BOLT;HEX. M10 X 30

desc: BOULON A 6 PANS

1шт.

3040

65.28652-0003A

BRACKET

desc: POULIE

1шт.

3050

65.28652-0002

BRACKET

desc: BOULON A 6 PANS

1шт.

3060

06.01283-3238

BOLT;HEX. M10X70

desc: COURROIE

1шт.

3070

06.16731-6108

WASHER;SPRING

desc: COURROIE

1шт.

3080

06.11063-8215

NUT;HEX. M10

desc: SUPPORT

1шт.

3090

65.19103-6010

EYE BOLT ASS'Y(aircon.)

SERIAL: 000303

1шт.

3090

65.19103-6012

EYE BOLT ASS'Y

SERIAL: 000304

1шт.

3100

65.90441-00011

BOLT;EYE

desc: . BOULON A 6 PANS

1шт.

3110

65.19107-0001

PIECE;GUIDE

desc: . BOULON A 6 PANS

1шт.

3120

65.93020-0055

BUSH

desc: . RONDELLE

1шт.

3130

06.11063-9217

NUT;HEX. M14X1.5

desc: . ECROU 6 PANS M10

3шт.

3140

06.01943-3319

BOLT;HEX. M12X1.5X40

desc: ECROU 6 PANS

1шт.
