Запчасти Doosan Daewoo ELECTRIC WIRING(2) BODY PARTS

-

4500-1187

ELECTRIC PARTS

SC: D

-2шт.

2

4530-1668

HARNESS;MAIN

SERIAL: 1001-1181

1шт.

2

4530-1668A

HARNESS;MAIN

SERIAL: 1182-1289

1шт.

2

4530-1668C

HARNESS;MAIN

SERIAL: 1290

1шт.

3

4530-1669

HARNESS;ENGINE

SERIAL: 1001-1130

1шт.

3

4530-1669A

HARNESS;ENGINE

SERIAL: 1131

1шт.

7

4530-1582

HARNESS;REAR WORKING LAMP

desc: FAISCEAU

1шт.

12

2553-1261D30

CABLE;BATT-EARTH 85BX450L

desc: CABLE MASSE E/G

1шт.

17

2553-1261D30

CABLE;PLATE-EARTH

desc: CABLE MASSE

1шт.

18

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS M10X1.5X16

5шт.

19

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

5шт.

20

S5010613

WASHER;PL M10

desc: RONDELLE

4шт.

21

2195-3500

BRACKET;HOUSING

desc: SUPPORT

3шт.

22

2197-1198

BRACKET;HOUSING

desc: SUPPORT

1шт.

23

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

5шт.

24

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

5шт.

25

2197-1660

BRACKET;HOUSING W15

desc: SUPPORT

1шт.

26

2197-1661

BRACKET;HOUSING W9

desc: SUPPORT

2шт.

27

2124-1509D1

CLIP d12/M8

desc: ATTACHE

6шт.

28

2124-1509D2

CLIP d18/M8

desc: ATTACHE

3шт.

29

2124-1509D3

CLIP d24/M8

desc: ATTACHE

15шт.

30

2124-1509D4

CLIP d30/M8

desc: ATTACHE

4шт.

32

2121-1305

NUT M8X1.25

desc: ECROU

28шт.

33

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

5шт.

34

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

10шт.

36

2124-1353D5

CLIP d20/M10

desc: CLIP

1шт.

41

4197-2051

BRACKET;CONNECTOR

desc: SUPPORT

1шт.

42

2120-2187

BOLT;STUD M8X1.25X20/M8

desc: BOULON A 6 PANS

5шт.

43

2120-2172

BOLT;STUD M10X1.5X25/M8

desc: BOULON A 6 PANS

2шт.

44

2120-2185

BOLT;STUD M12X1.5X15/M8

desc: BOULON A 6 PANS

1шт.

44

2120-2185A

BOLT;STUD M12X1.5X15/M8

desc: BOULON A 6 PANS

-1шт.

45

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

1шт.

46

2124-1353D8

CLIP d22/M12

desc: ATTACHE

1шт.
