Запчасти Doosan Daewoo ELECTRIC PARTS(4)-ELECTRIC BOX BODY PARTS

-

4500-1184

ELECTRIC BOX

SERIAL: 1001-1289

-2шт.

-

4500-1184A

ELECTRIC BOX

SERIAL: 1290

-2шт.

1

2510-1009

BOX ASS'Y;FUSE

desc: ENSEMBLE BOITE A FUSIBLES

1шт.

1A

2527-1016

FUSE;BLADE 10A

desc: . LAME DE FUSIBLE

8шт.

1B

2527-1017

FUSE;BLADE 15A

desc: . LAME DE FUSIBLE

10шт.

2

S3450983

SCREW M6X1.0X20

desc: VIS

2шт.

3

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

4

4190-2979

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

5

2523-9004A

CONTROLLER;STARTER

SERIAL: 1001-1032

1шт.

5

2543-9015

CONTROLLER;STARTER

SERIAL: 1033

1шт.

6

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

4шт.

7

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

8

2523-9007

CONTROLLER;PREHEAT

desc: COMMANDE PRECHAUFFAGE

1шт.

9

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

10

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

11

2525-1011

UNIT;BLINKER

desc: UNITE DE CLIGNOTANTS

1шт.

12

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

1шт.

13

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

1шт.

14

2543-9009A

UNIT;CONTROL

desc: MODULE DE COMMANDE

1шт.

15

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

4шт.

16

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

17

2537-9002

TIMER;WIPER

desc: TIMER ESSUIE-GLACE

1шт.

18

S3450973

SCREW M6X1.0X16

desc: VIS M6X1.0X20

4шт.

19

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

20

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

4шт.

21

2531-1003

CONVERTER;DC-DC

desc: CONVERTEUR

1шт.

22

S3450973

SCREW M6X1.0X16

desc: VIS M6X1.0X20

4шт.

23

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

24

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

4шт.

25

2516-1102A

BUZZER;PILOT

desc: VIBREUR PILOTE

1шт.

26

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

27

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

28

2544-9029

RELAY;HEAD LAMP

SERIAL: 1001-1065

1шт.

28

2544-9033

RELAY;HEAD LAMP

SERIAL: 1066

1шт.

29

2544-9029

RELAY;WORKING LAMP

SERIAL: 1001-1065

1шт.

29

2544-9033

RELAY;WORKING LAMP

SERIAL: 1066

1шт.

30

2544-9029

RELAY;ENGINE STOP

SERIAL: 1001-1065

1шт.

30

2544-9033

RELAY;ENGINE STOP

SERIAL: 1066

1шт.

31

2544-9029

RELAY;WIPER

SERIAL: 1001-1065

1шт.

31

2544-9033

RELAY;WIPER

SERIAL: 1066

1шт.

32

2544-9029

RELAY;RETURN TO DIG

SERIAL: 1001-1065

1шт.

32

2544-9033

RELAY;RETURN TO DIG

SERIAL: 1066

1шт.

33

2544-9029

RELAY;RAISE

SERIAL: 1001-1065

1шт.

33

2544-9033

RELAY;RAISE

SERIAL: 1066

1шт.

34

2544-9029

RELAY;FLOAT

SERIAL: 1001-1065

1шт.

34

2544-9033

RELAY;FLOAT

SERIAL: 1066-1181

1шт.

35

2544-9029

RELAY;SAFETY START

SERIAL: 1001-1065

1шт.

35

2544-9033

RELAY;SAFETY START

SERIAL: 1066

1шт.

36

2544-9029

RELAY;BACK

SERIAL: 1001-1065

1шт.

36

2544-9033

RELAY;BACK

SERIAL: 1066

1шт.

37

2544-9029

RELAY;BEAM LAMP

SERIAL: 1001-1065

1шт.

37

2544-9033

RELAY;BEAM LAMP

SERIAL: 1066

1шт.

38

S3450823

SCREW M5X0.8X10

desc: VIS

7шт.

39

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

7шт.

40

S4012233

NUT M5X0.8

desc: ECROU M5X0.8

3шт.

41

2190-2037D6

PLATE;NAME(RELAY)

desc: PLAQUE D'IDENTIFICATION

1шт.

42

2190-2037D7

PLATE;NAME(RELAY)

SERIAL: 1001-1181

1шт.

42

2190-2037D39

PLATE;NAME(RELAY)

SERIAL: 1182

1шт.

43

2190-2037D26

PLATE;NAME(RELAY)

desc: PLAQUE D'IDENTIFICATION

1шт.

44

4530-1667

HARNESS;ELECTRIC BOX

SERIAL: 1001-1181

1шт.

44

4530-1667A

HARNESS;ELECTRIC BOX

SERIAL: 1182-1289

1шт.

44

4530-1667C

HARNESS;ELECTRIC BOX

SERIAL: 1290

1шт.

45

2124-1509D3

CLIP d24/M8

desc: ATTACHE

5шт.

46

2124-1509D4

CLIP d30/M8

desc: ATTACHE

2шт.

47

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

7шт.

48

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

7шт.

49

S4012533

NUT M8X1.25

desc: ECROU

4шт.

50

S3450853

SCREW M5X0.8X16

desc: VIS

4шт.

51

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

4шт.

52

S5000213

WASHER;PLAIN M5

desc: RONDELLE

4шт.

53

4543-6034

CONTROLLER;T/M

SERIAL: 1066

1шт.
