Запчасти Doosan Daewoo CONTROL VALVE PIPING-3 SPOOL OPT BODY PARTS

-

4400-1982F2

CONTROL VALVE PIPING

SC: D

-2шт.

1

4195-3975A

SUPPORT

desc: SUPPORT

1шт.

2

4195-3976A

SUPPORT

desc: SUPPORT

1шт.

3

4195-3977

BRACKET

desc: SUPPORT

2шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

16шт.

5

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

16шт.

6

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

25шт.

7

S5110601

WASHER;SPRING M10X1.5

desc: RONDELLE ELASTIQUE M10

96шт.

8

S5010713

WASHER;PLAIN M12

desc: RONDELLE

10шт.

9

S5110701

WASHER;SPRING M12X1.75

desc: RONDELLE ELASTIQUE M12

32шт.

11

4182-1531

PIPE(L.H.)

desc: TUYAU

1шт.

12

4182-1532

PIPE(R.H.)

desc: TUYAU

1шт.

13

4420-9389

CONTROL VALVE 3-SPOOL(OPT)

desc: VANNE

1шт.

14

4182-1533

PIPE(L.H.)

desc: TUYAU

1шт.

15

4195-3979

BRACKET(L.H.)

desc: SUPPORT

1шт.

16

4195-3978

BRACKET(R.H.)

desc: SUPPORT

1шт.

17

4182-1534

PIPE(R.H.)

desc: TUYAU

1шт.

18

2184-1081D63

HOSE;BOOM 1"

desc: TUYAU FLEXIBLE

4шт.

19

4184-4030

HOSE;BUCKET 1"

desc: TUYAU FLEXIBLE

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

21

4183-4966A

PIPE;PUMP

desc: TUYAU

1шт.

22

4183-4967

PIPE;RETURN 3-SPOOL(OPT)

desc: TUYAU

1шт.

24

4183-4981

PIPE;BUCKET DUMP('B')

SERIAL: 1001-1220

1шт.

24

193-00248

PIPE;BUCKET DUMP('B')

SERIAL: 1221

1шт.

25

4183-4980

PIPE;BUCKET DUMP('B')

SERIAL: 1001-1220

1шт.

25

193-00249

PIPE;BUCKET DUMP('B')

SERIAL: 1221

1шт.

26

4183-4979

PIPE;BUCKET CROWD('A')

SERIAL: 1001-1220

1шт.

26

193-00250

PIPE;BUCKET CROWD('A')

SERIAL: 1221

1шт.

27

4183-4978

PIPE;BUCKET CROWD('A')

SERIAL: 1001-1220

1шт.

27

193-00251

PIPE;BUCKET CROWD('A')

SERIAL: 1221

1шт.

28

4140-1497

PIPE;BOOM DOWN('B')

desc: CONDUITE

1шт.

29

4140-1498

PIPE;BOOM DOWN('B')

desc: CONDUITE

1шт.

30

4140-1499

PIPE;BOOM UP('A')

desc: CONDUITE

1шт.

31

4140-1500

PIPE;BOOM UP('A')

desc: CONDUITE

1шт.

32

2124-1025D4

CLAMP;BUCKET CYL

desc: ATTACHE DE TUBE

2шт.

33

4195-4856A

BRACKET;BUCKET

SERIAL: 1001-1220

1шт.

33

195-00615

BRACKET;BUCKET

SERIAL: 1221

1шт.

34

4124-4031

CLAMP;BOOM PIPE

desc: ATTACHE DE TUBE

8шт.

35

S4012533

NUT M8X1.25

desc: ECROU

16шт.

36

S4012733

NUT M12X1.75

desc: ECROU

9шт.

37

2191-2205D4

CLAMP-HP/LP PIPE

desc: COLLIER

2шт.

38

4120-2142

BOLT;SOCKET M12X1.75X170

desc: BOULON A 6 PANS

3шт.

39

2181-9078

FLANGE;HALF 1.0" SAE

desc: FLASQUE EN DEUX PARTIES

40шт.

42

2180-1026D19

O-RING

desc: JOINT TORIQUE

24шт.

43

2180-1026D27

O-RING

desc: JOINT TORIQUE

1шт.

44

2180-1026D24

O-RING

desc: JOINT TORIQUE

7шт.

45

2181-2047

PLUG W/O-RING

desc: BOUCHON

6шт.

46

4621-2921

COVER 3-SPOOL(OPT.)

desc: COUVERCLE

2шт.

47

S2216161

BOLT;SOCKET M12X1.75X75

desc: BOULON A 6 PANS CREUX

4шт.

48

S2212461

BOLT;SOCKET M10X1.5X40

desc: BOULON A 6 PANS CREUX

26шт.

50

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

64шт.

51

S2215461

BOLT;SOCKET M12X1.75X40

desc: BOULON A 6 PANS CREUX M12X1.75X40

32шт.

52

S0560453

BOLT M12X1.75X35

desc: BOULON A 6 PANS

8шт.

53

S0515053

BOLT M12X1.75X25

desc: BOULON A 6 PANS

8шт.

54

S0515953

BOLT M12X1.75X65

desc: BOULON A 6 PANS

4шт.

55

S0561253

BOLT M12X1.75X75

desc: BOULON A 6 PANS

2шт.

56

S0511953

BOLT M10X1.5X22

desc: BOULON A 6 PANS

4шт.

57

S5010613

WASHER;PLAIN M10

desc: RONDELLE

4шт.

58

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX M10X1.5X35

8шт.
