Запчасти Doosan Daewoo CAM SHAFT ENGINE PARTS

1

65.04401-0027B

SHAFT;CAM

SERIAL: 040827

1шт.

1

65.04401-0027C

SHAFT;CAM

SERIAL: 061127

1шт.

1

65.04401-0027D

SHAFT;CAM

SERIAL: 061128

1шт.

2

65.90720-0099

WASHER;THRUST

desc: RONDELLE

1шт.

3

65.98112-0038

FLANGE

desc: BRIDE

1шт.

4

65.90001-6003

BOLT ASS'Y M6X14

desc: BOULON A 6 PANS

2шт.

5

06.22022-1016

PIN;DOWEL

desc: GOUJON

1шт.

6

65.04501-0057

GEAR;CAM SHAFT

desc: PIGNON

1шт.

7

06.01913-3120

BOLT ASS'Y M8X45

desc: BOULON A 6 PANS

4шт.

8

65.04505-5008A

IDLE GEAR ASS'Y

desc: BARBOTIN

1шт.

9

65.04505-0005

GEAR;CAM SHAFT IDLE

SC: D

1шт.

10

65.04507-0003A

BUSH;IDLE GEAR

SC: D

1шт.

11

65.04506-0008

PIN;IDLE GEAR

desc: GOUJON

1шт.

12

65.90720-0019

WASHER;IDLE GEAR THRUST

desc: RONDELLE

1шт.

13

06.01914-3126

BOLT ASS'Y M8X75

desc: BOULON A 6 PANS

2шт.

14

65.04301-0005

TAPPET;VALVE

desc: TRINGLERIE

12шт.

15

65.04302-5010

PUSH ROD ASS'Y

desc: TIGE

12шт.

16

65.04101-0041

VALVE;INTAKE(ALTV)

desc: VANNE

6шт.

17

65.04101-0042

VALVE;EXHAUST(ALTV)

desc: VANNE

6шт.

18

65.04102-6002

SPRING VALVE ASS'Y

desc: RESSORT

6шт.

19

65.04102-0003

SPRING;EXHAUST VALVE(OUTER)

desc: . RESSORT

1шт.

20

65.04102-0004

SPRING;EXHAUST VALVE(INNER)

desc: . RESSORT

1шт.

21

65.04102-0007

SPRING;INTAKE VALVE

desc: RESSORT

6шт.

22

65.04103-0013

RETAINER;VALVE SPRING

desc: ARRETOIR

12шт.

23

65.04103-0009

SEAT;VALVE SPRING

desc: SIEGE

12шт.

24

65.04104-0006

COTTER;VALVE

desc: CLAVETTE

24шт.

25

65.04902-0013

SEAL;VALVE STEAM

desc: JOINT

12шт.

26

65.04200-6025D

ROCKER ARM SHAFT ASS'Y

SERIAL: 060621

3шт.

26

65.04200-6025E

ROCKER ARM SHAFT ASS'Y

SERIAL: 060622

3шт.

27

65.04201-5013E

ROCKER ARM ASS'Y

desc: . BALANCIER

4шт.

28

65.04205-0003

BOLT;ADJUSTING M10X1.0

SERIAL: 060621

4шт.

28

65.04205-0003A

BOLT;ADJUSTING M10X1.0

SERIAL: 060622

4шт.

29

65.90501-0003

NUT;HEX. M10X1.0

desc: . ECROU

4шт.

30

65.04203-5009

ROCKER ARM SHAFT ASS'Y

desc: . ENSEMBLE AXE DE BALANCIER

1шт.

31

65.04203-0009A

ROCKER ARM SHAFT

SC: D

1шт.

32

65.90302-0012

PLUG

SC: D

2шт.

33

65.04202-0017A

BRACKET;ROKER ARM

desc: . SUPPORT

2шт.

34

65.97601-0055

SPRING

desc: . RESSORT

1шт.

35

65.90710-0039

WASHER;ROCKER ARM

desc: . RONDELLE

2шт.

36

06.29010-0120

RING;SNAP 24X1.2

desc: . ANNEAU DE SOUTIEN

2шт.

37

65.90020-0056

BOLT;HEX. M12X1.5X80

desc: . BOULON A 6 PANS

2шт.

38

06.01013-9221

BOLT;HEX. M10X80

desc: . BOULON A 6 PANS

2шт.

39

06.16731-2108

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

2шт.

40

06.15030-0514

WASHER;PLAIN

desc: . RONDELLE PLATE

2шт.
