Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

920-00092

COOLER & HEATER ASS'Y

SERIAL: 3001-3207

-2шт.

-

920-00092A

COOLER & HEATER ASS'Y

SERIAL: 3208

-2шт.

13

2520-6004

CONDESER ASS'Y

desc: CONDENSATEUR

1шт.

13A

2520-6005

CORE ASS'Y;CONDENSER

desc: . NOYAU

1шт.

13B

2538-6018

FAN MOTOR ASS'Y

desc: . MOTEUR

1шт.

13C

2520-6006

NET;CONDENSER

desc: . FILET

1шт.

14

S0512053

BOLT M10X1.5X25

desc: BOULON

6шт.

15

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

6шт.

16

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

6шт.

17

195-00140

BRACKET;CONDENSER

desc: SUPPORT

1шт.

18

195-01170A

BRACKET;CONDENSER

desc: SUPPORT

1шт.

19

S0558553

BOLT M10X1.5X50

desc: BOULON

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

21

2114-1058D1

WASHER

desc: RONDELLE

4шт.

22

2512-1077

RUBBER;CUSHION

desc: CAOUTCHOUC

8шт.

23

2185-1697D1

HOSE;LIQUID(1) 610L

desc: TUYAU FLEXIBLE

1шт.

23A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

24

4185-1775D4

HOSE;LIQUID(2) 2100L

desc: TUYAU FLEXIBLE

1шт.

24A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

25

2204-6039A

RECEIVER;DRIER

desc: RESERVOIR DESSICATEUR

1шт.

26

S0508653

BOLT M8X1.25X16

desc: BOULON

2шт.

27

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

29

S0509053

BOLT M8X1.25X25

desc: BOULON

6шт.

30

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

31

2114-1058D29

WASHER

desc: RONDELLE

6шт.

32

2185-1308D7

HOSE 4000L

desc: TUYAU FLEXIBLE

2шт.

33

2186-9005

COCK

desc: PURGE

1шт.

34

S8450016

CLAMP;HOSE

desc: FIXATION DE TUYAU

4шт.

35

124-00208D3

CLIP D20/M8

desc: CLIP

4шт.

36

124-00209D1

CLIP D20/M8

desc: CLIP

3шт.

37

2121-1305

NUT

desc: ECROU

5шт.

40

2124-1622D3

CLIP;BAND 280L

desc: CLIP

10шт.
