Запчасти Doosan Daewoo TURBO CHARGER & OIL PIPE ENGINE PARTS

1

65.09100-7083

TURBOCHARGER ASS'Y

desc: DOUILLE ACIER

1шт.

2

65.90201-0073

BOLT;STUD

desc: BOULON DE GOUJON

4шт.

3

65.09901-0018A

GASKET

desc: JOINT

1шт.

4

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

5

06.11024-9202

NUT M10X1.25

desc: ECROU

4шт.

6

65.90201-0072

BOLT;STUD M10X1.5X30

desc: BOULON DE GOUJON

6шт.

7

65.09901-0012

GASKET

desc: JOINT

1шт.

8

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

9

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

6шт.

10

65.05701-5480

OIL PIPE ASS'Y(C/B-T/C)

SERIAL: 020821

1шт.

10

65.05701-5480A

OIL PIPE ASS'Y(C/B-T/C)

SERIAL: 020822

1шт.

11

06.15010-2311

WASHER 8.4

desc: RONDELLE

2шт.

12

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

13

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

2шт.

14

06.78144-2403

SCREW;HOLLOW M12X1.5

desc: VIS

2шт.

15

06.56190-0704

RING;SEAL

desc: BAGUE

4шт.

16

65.98131-5003

ADAPTER FLANGE ASS'Y

desc: RACCORD ADAPTEUR

1шт.

17

65.96601-0046A

GASKET;OIL PIPE ADAPTER

desc: JOINT

1шт.

18

06.01913-3114

BOLT ASS'Y M8X22

desc: BOULON A 6 PANS

2шт.

19

65.05701-5481

OIL PIPE ASS'Y(T/C-C/B)

desc: CONDUITE

1шт.

20

65.96601-0045A

GASKET

desc: JOINT

2шт.

21

65.05740-5005

BRACKET;OIL PIPE

desc: SUPPORT

1шт.

22

65.90020-0068

BOLT ASS'Y M8X16

desc: BOULON A 6 PANS

1шт.

23

06.01923-3217

BOLT ASS'Y M10X30

desc: BOULON A 6 PANS

1шт.

24

65.05701-5336A

OIL PIPE ASS'Y(T/C-C/B)

desc: CONDUITE

1шт.

26

06.01913-3112

BOLT ASS'Y M8X18

desc: BOULON A 6 PANS

2шт.

27

06.01913-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

1шт.

28

65.90201-0075

BOLT;SPACER

desc: BOULON A 6 PANS

1шт.

29

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

30

06.15010-2311

WASHER

desc: RONDELLE

1шт.

31

65.96301-0327

HOSE;RUBBER

SERIAL: 040303

1шт.

31

65.96301-0327A

HOSE;RUBBER

SERIAL: 040304

1шт.

32

06.67020-0105

CLAMP

desc: COLLIER

2шт.

33

65.09411-5059

INLET

desc: PRISE

1шт.

34

65.96301-0279

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

35

06.67020-0109

CLAMP;HOSE

desc: COLLIER

2шт.

36

65.09440-0010

BRACKET

desc: SUPPORT

1шт.

37

06.01923-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

2шт.
