Запчасти Doosan Daewoo PISTON ENGINE PARTS

1

65.02501-0785

PISTON

desc: PISTON

6шт.

2

65.02503-0054

RING;TOP

desc: BAGUE

6шт.

3

65.02503-0120

RING;2ND(INNER CUT)

desc: BAGUE DE SOUTIEN

6шт.

4

65.02503-0115

RING;OIL

desc: BAGUE

6шт.

5

65.02502-0010

PIN;PISTON 42X20X95

desc: GOUJON

6шт.

6

06.29020-0126

RING;SNAP 42X1.75

desc: BAGUE

12шт.

7

65.02401-6101E

CONNECTING ROD ASS'Y

desc: BIELLE

6шт.

8

65.02401-0030

ROD;CONNECTING

SC: D

1шт.

9

65.90020-0009D

BOLT;CON-ROD

desc: . BOULON A 6 PANS

2шт.

10

65.02405-0015C

BUSH;CON-ROD

SC: B

1шт.

11

65.91301-0010

PIN;DOWEL

desc: . GOUJON

2шт.

12

65.02410-0010

BEARING;CON-ROD(STD)

desc: PALIER

6шт.

12

65.02410-0011

BEARING;CON-ROD(0.25)

desc: PALIER

6шт.

12

65.02410-0012

BEARING;CON-ROD(0.50)

desc: PALIER

6шт.
